ABB i-bus® KNX
WaveLINE Wireless Control – RF Sensors

01 02

03 04 05

01 SM WaveLINE movement detector, 02 WaveLINE media converter TP-RF,
Article-No. 6747 AGM-204-500 Article-No. 6770-500
The WaveLINE Busch-Watchdog 220 is a battery- The KNX and Busch radio control are coupled
operated movement detector. Since it is via the WaveLINE media converter TP-RF.
installed without cables it can be mounted in the Telegrams can be exchanged in both directions.
most ideal position. The battery has a service One application serves to transmit the window
life of 5 years. sensor to the KNX system.

03 Window sensor, 04 Universal detector, 05 Remote control RF,
Article-No. 6720-64 Article-No. 6721-64 Article-No. 6780-500
14
The WaveLINE window sensor is retrofitted The WaveLINE universal detector is suited for The remote control is used as mobile control
between the window and window handle, which skylights or sliding doors and is activated via for the WaveLINE. Loads can be controlled
means the original window handle is retained. a reed contact. The universal detector has a individually and scenes can be started.
The window handle is used for the following second channel which can be permanently wired
window positions: opened, tilted and closed. to a floating contact (NO or NC contacts).

Control elements

Switch ranges 1gang 2gang 4gang 1gang 2gang
pure stainless steel 6731-866-500 6732-866-500 6733-866-500
solo® 6731-xx-500 6732-xx-500 6733-xx-500
Busch-axcent® 6731-xx-500 6732-xx-500 6733-xx-500
future® linear 6731-xx-500 6732-xx-500 6733-xx-500
Reflex SI 6731-214-500 6732-214-500
Busch-Duro 2000® SI 6731-212-500 6732-212-500
