ABB-free@home®
DINRail

Binary Input, 4-fold, FM
Conventional push-buttons or auxiliary contacts can be connected to 4 channels. The infor-
mation of the contact enquiry can be used for activating ABB-free@home® actuators or for
recording status information.
The contact polling voltage is made available from the binary input itself. Extension of the
connecting cables possible by a maximum of 10 m.
Flush-mounted device for installation in a 60 mm device box or distribution box.
The bus can be connected via enclosed terminal block.
Bus voltage: 24 V
Inputs: 4
Polling voltage: 20 V-,
Protection class (Device): IP 20
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 39 mm x 40 mm x 12 mm

Bbn Order details Price Weight Pack
4016779 1 piece 1 piece unit
EAN Type code Order code kg pc.
941884 BI-F-4.0.1 2CDG510003R0011 1
