21/15

—
Enclosures
Accessories for IP44, IP55 and IP65 Junction boxes

Technical characteristics of metric cable clamps: Technical characteristics nuts of with metric pitch collar
Protection degree IP68 Material: polyamide 6.6, self-extinguishing material according to
Material: polyamide 6.6, self-extinguishing material according to UL94 V2 Standard and resistant to abnormal heat and to fire up to
UL94V2 Standard and resistant to abnormal heat and to fire up to 750°C (glow wire test) according to IEC 60695-2-11 Standard
750°C (glow wire test) according to IEC 60695-2-11 Standard Operational temperature: from -20°C up to +120°C (continuous) from
-20°C up to +120°C (short period of time)
Operational temperature: from -20°C up to +120°C
(short period of time) Colour: RAL 7035 grey
Colour: RAL 7035 grey; Thread pitch: 1.5 mm; Thread angle: 60°.
Neoprene seal;
Thread pitch: 1.5 mm; Thread angle: 60°
Tightening with a plate crown on the whole diameter of cable
(excluded the possibility to damage the cable itself)
Possibility to recover the cable clamp without compromising
its efficiency.

Cable glands and nuts - PG pitch
Pitch Torque For cables Cable gland Nut x cable gland Cable Nuts x
values diameter clamp cable
Box/pack Box/pack
PG pitch Min Max
Pg N x m (mm) (mm) Order code Price Order code No Items No Items
9 3.75 6.5 8.5 00931 00941 100/500 100/3000
11 3.75 8 10 00932 00942 100/500 100/3000
13.5 3.75 8 11 00933 00943 50/500 50/1500
16 5 11 14 00934 00944 50/300 50/1500
21 7.5 14.5 18 00935 00945 50/300 50/1500
PG pitch 29 7.5 19 26 00936 00946 25/150 50/600
36 7.5 30 34 00937 00947 25/75 25/300
42 7.5 30 38 00938 00948 15/60 25/300
In compliance with CEI EN 50262 Standard.

Cable glands and nuts - metric pitch
metric pitch
Pitch Torque Cables diameter Cable gland Nut Box/pack Cable
values clamp
Box/pack

Min Max
Pg N x m Order code Price Order code No Items No Items
(mm) (mm)
metric pitch
12 x 1.5 2.7 3.5 7 00951 00961 100/1200 100/3000
16 x 1.5 5 5.5 10 00952 00962 100/500 100/3000
20 x 1.5 7 7 13 00953 00963 100/500 50/1500
25 x 1.5 7.5 10 17 00954 00964 50/250 50/1500
32 x 1.5 8 12 21 00955 00965 25/150 50/500
40 x 1.5 8 19 28 00956 * 00966 25/75 25/300
50 x 1.5 10 27 35 00957 * 00967 15/60 25/300
63 x 1.5 10 34 45 00958 * 00968 10/40 20/100
In compliance with CEI EN 50262 Standard.
* Cable clamps and M40, M50 and M63 nuts are available on request.

21
