Page 27 - Panel_mount_Switches

DIMENSIONS

Type of C/o DIMENSION Type of C/o Type of C/o DIMENSION Type of C/o
Switches A B C D E F G Mechanism Switches A B C D E F G Mechanism
CSSD25D4CO 187 120 52 95 180...210 120 86 CSSDZW6 CSSD200K00D4/K4CO 635 430 225 335 250...325 580 251 CSSDZW11
CSSD40D4CO 187 120 52 95 180...210 120 86 CSSDZW6 CSSD630K4CO 653 430 207 360 250...325 580 299 CSSDZW11
CSSD63D4CO 277 180 83 145 180...210 180 145 CSSDZW6/1 CSSD800K4CO 653 430 207 384 250...325 580 323 CSSDZW11
CSSD125D4CO 277 180 83 145 180...210 180 145 CSSDZW6/1 CSSD1000/1250K4CO 984 610 240 457 300...350 800 412 CSSDZW12
CSSD1600/1800K4CO 984 610 240 635 300...350 800 590 CSSDZW12
CSSD2500/3150K4CO 984 610 240 800 445...495 769 624 CSSDZW12
INDEX
Part No. Page Part No. Page Part No. Page Part No. Page Part No. Page
No. No. No. No. No.
CSCS1000K3CO 21 CSDA 8 5 CSSD630K3 4 CSSDF315B3 13 CSSDF-ZX 33 4
CSCS1000K4CO 21 CSDB 16 4 CSSD630K4 4 CSSDF315B4 13 CSSDF-ZX 34 4
CSCS1250K3CO 21 CSDB 20 4,12 CSSD800K3 4 CSSDF315D3 13 CSSDF-ZX 35 5
CSCS1250K4CO 21 CSDB 28 5,13 CSSD800K4 4 CSSDF315D4 13 CSSDF-ZX 36 5
CSCS1600K3CO 21 CSDB-25 20 CSSDF ZX 85 13 CSSDF32B3 12 CSSDF-ZX 46 12
CSCS1600K4CO 21 CSDB-30 21 CSSDF ZX 86 12 CSSDF32B4 12 CSSD-ZW4 4,5
CSCS160DM3CO 20 CSP-12X255 4,5,13,14 CSSDF ZX 87 12 CSSDF32D3 12 CSSDZW6/1 4
CSCS160DM4CO 20 CSP-12X465 4,5,13,14,20,21 CSSDF ZX 88 13 CSSDF32D4 12 CSSD-ZX95 4,5
CSCS200DM3CO 20 CSP-6X165 4,12 CSSDF100B3 12 CSSDF400B3 13 CSSF-ZW1 12
CSCS200DM4CO 20 CSP-6X340 4,13 CSSDF100B4 12 CSSDF400B4 13 CSSF-ZW11 4
CSCS250DM3CO 20 CSSD1000K3 5 CSSDF100D3 12 CSSDF400D3 13 CSSF-ZW12 5,13
CSCS250DM4CO 20 CSSD1000K4 5 CSSDF100D4 12 CSSDF400D4 13 CSSF-ZW12/1 13
CSCS315DM3CO 20 CSSD1250K3 5 CSSDF125B3 12 CSSDF630B3 13 CSWPL0026 13
CSCS315DM4CO 20 CSSD1250K4 5 CSSDF125B4 12 CSSDF630B4 13 CSWPL0029 13
CSCS400K3CO 21 CSSD1600K3 5 CSSDF125D3 12 CSSDF630D3 13 CSWPL0032 13
CSCS400K4CO 21 CSSD1600K4 5 CSSDF125D4 12 CSSDF630D4 13 CSWPL0033 13
CSCS630K3CO 21 CSSD160DM3 4 CSSDF160B3 12 CSSDF63B3 12 CSWPL0036 13
CSCS630K4CO 21 CSSD160DM4 4 CSSDF160B4 12 CSSDF63B4 12 CSWPL0039 13
CSCS63DM3CO 20 CSSD1800K3 5 CSSDF160D3 12 CSSDF63D3 12 ET323 12
CSCS63DM4CO 20 CSSD1800K4 5 CSSDF160D4 12 CSSDF63D4 12 ET327 4,12
CSCS800K3CO 21 CSSD2500K3 5 CSSDF200B3 13 CSSDF800B3 13 ET328 4
CSCS800K4CO 21 CSSD2500K4 5 CSSDF200B4 13 CSSDF800B4 13 ET329 4,13
CSCS-ZX1-L 20 CSSD250K3 4 CSSDF200D3 13 CSSDF800D3 13 ET330 4
CSCS-ZX1-U 20 CSSD250K4 4 CSSDF200D4 13 CSSDF800D4 13 HMK-1 4,13
CSCS-ZX2 20,21 CSSD3150K3 5 CSSDF250B3 13 CSSDF-ZW15 4 HMK-3 4,13
CSCS-ZX3-L 20 CSSD3150K4 5 CSSDF250B4 13 CSSDF-ZX 1 4 SF702-K 4,12,20
CSCS-ZX3-U 20 CSSD400K3 4 CSSDF250D3 13 CSSDF-ZX 16 4 SF703-K 4,13,20
CSCS-ZX4 20,21 CSSD400K4 4 CSSDF250D4 13 CSSDF-ZX 32 12 SF704-K 4,5,13,21
