INSTALL ATION 1/1
01

—

Installation

Installation environment
1/2 Temperature
1/2 Environmental conditions
1/2 Shocks and vibrations
1/2 Electromagnetic compatibility
1/3 Degrees of protection
1/3 Installation position
Temperature performance
1/4 Circuit-breakers with thermal-magnetic trip units
1/6 Circuit-breaker with magnetic only or electronic trip units
and switch-disconnectors
1/8 Power losses
Insulation distances
1/10 Clearances for installation in metallic cubicles
1/12 Alternating Current (AC) application
1/13 Direct Current (DC) application
1/14 Minimum clearance between two side by side circuit-breakers
1/16 Minimum clearance between two superimposed circuit-breakers
1/17 The first insulated anchor
Special applications
1/19 Use of direct current apparatus
Characteristic curves
1/21 Example of curves reading
1/24 Trip curves with thermal-magnetic trip unit
1/30 Trip curves with electronic trip unit Ekip Dip
1/44 Trip curves with electronic trip unit Ekip Touch and Hi-Touch
1/54 Specific let-through energy curves
1/64 Limiting curves
