ENCLOSURE VENTILATION & HEATING

FAN FILTER UNITS (RAL 7035) 230VAC
Dimensions (mm)
W x H x D Air Flow Part No.
105 x 105 x 60 23 m³/H B flow FPF08KU230B-110 #
150 x 150 x 64 57 m³/H B flow FPF12KU230BE-110 #
204 x 204 x 90 110 m³/H B flow FPF13KPU230BE110 #
250 x 250 x 113 240 m³/H B flow FPF15KU230BE-110 #
250 x 250 x 117 360 m³/H B flow FPF15KGU230BE120 #
FPF08KU230B-110 325 x 325 x 142 650 m³/H B flow FPF20KGU230B-110
325 x 325 x 152 520 m³/H B flow FPF20KU230BE-120 #
A ow B ow
325 x 325 x 142 650 m³/H A flow FPF20KGU230BER12 ^
# Fan units can be reverse mounted for ‘A’ flow.
^ Fan units can be reversed for ‘B’ flow.
OUTLET GRILL FILTER UNITS (RAL 7035)
Size (mm) Part No.
105 x 105 Grill Filter Set FPF08KUG-101
150 x 150 Grill Filter Set FPF12KUG-100
204 x 204 Grill Filter Set FPF13KUG-100 METAL
250 x 250 Grill Filter Set FPF15KUG-100 ENCLOSURES
325 x 325 Grill Filter Set FPF20KUG-100

SPARE FILTERS IP54
FPF08KUG-101
Description Part No.
Filters for FPF08K M08FPFK
Filters for FPF12K M12FPFK
Filters for FPF13K M13FPFK
Filters for FPF15K M15FPFK
Filters for FPF20K M20FPFK

SPARE FILTERS IP55
Description Part No.
Filters for FPF13K M13FPF5K
Filters for FPF15K M15FPF5K
Filters for FPF20K M20FPF5K

STAINLESS STEEL COVERS - IP55
Size
Description H (mm) W (mm) D (mm) Part No.
To suit FPF08 161 156 41.5 SSC-08
To suit FPF12 195 190 41.5 SSC-12
To suit FPF13 246 241 41.5 SSC-13
To suit FPF15 293 288 41.5 SSC-15
To suit FPF20 361 356 41.5 SSC-20

ROOF EXHAUST UNIT
SSC-08
Rated Rated Max Air Rated
Current Power Flow Weight Temp. Range
(mA) (W) (m³/h) (kg) (ºC) Part No.
IP24 - 230A.C. 50/60Hz
341/340 78/82 530/563 2.0 -10 + 60 TP19U230B
IP54 - 230A.C. 50/60Hz
350/334 80/80 420/460 2.1 -10 + 60 TP19U230B54

TP19U230B
