P. 8
PHOTOVOLTAIC
DC ISOLATORS
(Series M)
FEATURES: OTDC SERIES M UP TO 1500V DC
• Ideal for Farm Scale DC
Combiner boxes Current Voltage/ Voltage/ Short time
Rating Switch Pole Withstand Poles Part No.
• Supplied as switch only,
(DC-PV2) (V DC) (V DC) (kA RMS 1s)
refer P12-13 for handles
and shafts 315 OTD315FV11
• High performance with
low watts loss 400 1500 750 10 2 OTDC400FV11
• Standards IEC 60947-3,
500 OTDC500FV11
with DC-PV2 rating
• Efficient modular design, 315 OTD315FV22
easy install
400 1500 1500 (1) 10 4 OTDC400FV22
• Adjustable mounting feet
500 OTDC500FV22
(1) For PV solar applications use OTDCKIT400FS11 kit or OTDCKIT600FS11, 2
poles in series in each leg
OTDC315FV22
FEATURES: OTDC SERIES M UP TO 1500V DC
• Ideal for Farm Scale DC
Combiner boxes Current Voltage/ Voltage/ Short time
Rating Switch Pole Withstand Poles Part No.
• Supplied as switch only,
(DC21B) (V DC) (V DC) (kA RMS 1s)
refer P12-13 for handles
and shafts
630 OTDC630FV11
• High performance with 1500 750 10 2
low watts loss 800 OTDC800FV11
• Standards IEC 60947-3,
Current Voltage/ Voltage/ Short time
with DC-PV2 rating
Rating Switch Pole Withstand Poles Part No.
• Efficient modular design,
(DC-PV2) (V DC) (V DC) (kA RMS 1s)
easy install
• Adjustable mounting feet 630 OTDC630FV22-PV2 (2)
800 1500 1500 (2) 10 4 OTDC800FV22-PV2 (2)
1000 (3) OTDC1000FV22 (2)
(2) 4-pole-types with 2-poles in parallel _22 models, OTDCKIT800FS11 is
included to the package – installation mandatory
(3) DC-PV1 rated only.
OTDC1000FV22 with OTDCKIT800FS11
8 | Solar DC Products
