ORDER INFORMATION

1 INCL VENTILATIONS AFDÆKNING
LOUVRE COVER

TECHNO MODULE TYPE DESCRIPTION SIZE (W×H) VENTILATION AREA WEIGHT RAL 7035 FTF.

VERSION 3
ORDER No.
(mm )
2
(kg)
17707
LOUVRE COVER
2 548
LCO 4.2
2.17
400 × 200
LOUVRE COVER
LCO 6.2
800 × 200
4.34
LOUVRE COVER
17727
5 096
LCO 8.2
2mm Covers on request 600 × 200 2 548 3.49 17717
COVER WITH CABLE GLANDS
INCL AFDÆKNINGER FOR KABEL
GENNEMFØRING

WEIGHT VERSION 3
TYPE DESCRIPTION SIZE (W×H) ORDER No.
(kg) RAL 7035 FTF.
CCG 4.2 COVER WITH CABLE GLAND 400 × 200 1.58 16147
CCG 4.4 COVER WITH CABLE GLAND 400 × 400 2.61 16157
CCG 4.6 COVER WITH CABLE GLAND 400 × 600 3.68 16167
CCG 6.2 COVER WITH CABLE GLAND 600 × 200 2.11 16177
CCG 6.4 COVER WITH CABLE GLAND 600 × 400 3.82 16187
CCG 6.6 COVER WITH CABLE GLAND 600 × 600 5.24 16197
2mm Covers on request

GLAND PLATE

KABELFLANGE
x 04 Nos.
Quick gland plate Steel gland plate

Steel gland plate with studs
ORDER No.
TYPE DESCRIPTION SIZE (W×H) WEIGHT (kg)
RAL 7035 FTF.
QG QUICK GLAND PLATE 216 × 86 0.32 14734
SG 216 STEEL GLAND PLATE 216 × 86 0.22 14724
SGSG 216 STEEL GLAND PLATE WITH STUD 216 × 86 0.32 51005
