3/296 ABB MOTOR PROTECTION AND CONTROL

—

Auxiliary contact blocks for AF116 ... AF2850 contactors
for severe industrial environments

The auxiliary contact blocks are used for the operation of auxiliary and control circuits for severe
industrial environments.
03
Types of auxiliary contact blocks for side mounting:
• CEL 1-pole block, with built-in microswitch IP67 degree of protection (IP20 on terminals).
Instantaneous N.O. or N.C. contact.

1SFC101214V0001 For clipping onto the right- and/or left-hand side of the contactors.
protected against accidental direct contact and bear the corresponding function marking.
CEL19 The auxiliary contact blocks are equipped with screw type connecting terminals delivered open,
For contactors Auxiliary Type Order code Pkg Weight
contacts qty (1 pce)

kg
1SFC101083V0001 Side-mounting instantaneous auxiliary contact blocks 1SFN010832R1010 1 0.040
CEL19-10
1 0
AF116 ... AF370
0.050
1SFN010716R1010
CEL18-10
1 0
CEL18 AF400 ... AF2850 0 1 CEL19-01 1SFN010832R1001 1 1 0.040
0 1 CEL18-01 1SFN010716R1001 1 0.050
For each contactor type, refer to "Accessory fitting details" table.
