4/30 ABB MOTOR PROTECTION AND CONTROL

—
KC6 4-pole mini contactor relays – with soldering pins

DC operated

KC6..P 4-pole mini-contactor relays are space optimized control products mainly used for control
functions or for small loads up to 4 A.
These contactors are designed with 4 poles with various contact combinations:
2CDC211025F0011 • control circuit: DC operated, low consumption coil (3.5 W at pull-in and at holding)
• hum-free coil
• contacts configurations 22 and 31 fulfill the requirements for Mechanically linked contacts acc.
to annex L of IEC/EN 60947-5-1
04
KC6-22Z-P • add-on auxiliary contact blocks for side mounting
• suitable for soldering on PCB boards
Rated control circuit voltage Type Order code Pkg Weight
Uc qty (1 pce)
2CDC211023F0011 2 N.O. + 2 N.C. contacts
kg
V DC

24 KC6-22Z-P-01 GJH1213009R0221 10 0.170
KC6-31Z-P
3 N.O. + 1 N.C. contacts
24 KC6-31Z-P-01 GJH1213009R0311 10 0.170

4 N.O. contacts
24 KC6-40E-P-01 GJH1213009R0401 10 0.170
Other types on request.

47.7 1.88" 4.3 0.17"
47.5 1.87" 44.7 1.76"

45.2 1.78" 42.2 1.66" 1 0.04"

KC6
Main dimensions mm, inches
