Multimedia / communication adapters

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
USB connection unit ) Cinch-jacks
with screw-type terminals and strain relief for communication adapter
Suitable for telephone connection unit cover plates To link analogue audio devices like audio-receiver,
2539-21x and 1766-xxx. amplifier and HiFi-sets.
To link mobile devices like e.g. printer, scanner, USB- Audio-band 20Hz - 20kHz.
sticks or digital cameras etc. Marked white: audio , channel left.
USB-type A, USB 2.0 compatible. With soldering tag.
For 5-wire USB- cables via srew-type terminals. Protection class (Device): IP 20
For trunk systems, flush-mounted wall boxes and alpine white 0263/04-500 2CKA000230A0451 1
underfloor systems.
For easy installation and to follow the valid bending
radii the "Kaiser- electronic-wall-box" type 1068-02 or Cinch-jacks
9062-74 is recommended. for communication adapter
Without cover plate. To link analogue audio devices like audio-receiver,
Without claws. amplifier and HiFi-sets.
Protection class (Device): IP 20 Audio-band 20Hz - 20kHz.
Mounting depth: 34 mm Marked black: audio , channel left.
white 0261/11-500 2CKA000230A0418 1 With soldering tag.
Protection class (Device): IP 20
grey 0261/13-500 2CKA000230A0420 1
black 0263/05-500 2CKA000230A0452 1
alpine white 0261/12-500 2CKA000230A0419 1
1) Please follow the recommendations of the cable and device producers for the max.
USB cable lengths. Cinch-jacks
for communication adapter
To link analogue audio devices like audio-receiver,
Communication adapter amplifier and HiFi-sets.
for BNC-F Duct-jacks Audio-band 20Hz - 20kHz.
11
Suitable for telephone connection unit cover plates Marked red: audio , channel left.
2539-21x and 1766-xxx. With soldering tag.
To support 1 or 2 jacks. Protection class (Device): IP 20
For trunk systems, flush-mounted wall boxes and
underfloor systems. Red 0263/06-500 2CKA000230A0453 1
Without cover plate.
Without claws. Cinch-jacks
Protection class (Device): IP 20
for communication adapter
white 0262/11-500 2CKA000230A0436 1 For connecting analogue video devices, such as
DVD players, hard disc recorders, video recorders or
grey 0262/13-500 2CKA000230A0438 1
receivers.
alpine white 0262/12-500 2CKA000230A0437 1 Marked yellow: audio , channel left.
With soldering tag.
Protection class (Device): IP 20
F duct-jack
for communication adapter yellow 0263/07-500 2CKA000230A0454 1
For connection of antenna cables e.g.. for TVs with
integrated TV-tuner and satellite receiver.
With screw-type terminals. Communication adapter
For trunk systems, flush-mounted wall boxes and for Mini-jacks 3,5mm.
underfloor systems. Suitable for telephone connection unit cover plates
Protection class (Device): IP 20 2539-21x and 1766-xxx.
To support 1 or 2 jacks.
metal clad 0262-500 2CKA000230A0440 1 For trunk systems, flush-mounted wall boxes and
underfloor systems.
Without cover plate.
Communication adapter
for Cinch-jacks Without claws.
Suitable for telephone connection unit cover plates Protection class (Device): IP 20
2539-21x and 1766-xxx. white 0264/11-500 2CKA000230A0458 1
To support 1 or 2 jacks. grey 0264/13-500 2CKA000230A0460 1
For trunk systems, flush-mounted wall boxes and
underfloor systems. alpine white 0264/12-500 2CKA000230A0459 1
Without cover plate.
Without claws. Mini-jack 3,5 mm
Protection class (Device): IP 20
for communication adapter
white 0263/11-500 2CKA000230A0444 1 For the connection of mobile terminal devices such as
grey 0263/13-500 2CKA000230A0446 1 MP3 player (stereo), mobile telephone and smartphones.
Audio-band 20Hz - 20kHz.
alpine white 0263/12-500 2CKA000230A0445 1 With soldering tag.
Protection class (Device): IP 20
chrome gloss 0264-500 2CKA000230A0462 1
