Busch-axcent®
Rocker switches / push switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
1
Rocker ) ) Cover plate
with labelling field For card switch.
With bell symbol. For insert 2025 U.
With pilot lamp for uniform illumination of the labelling Suitable for cards sized 54 x 86 mm.
field. The inner part of the cover plate is made of light-
For flush-mounted push switch. conducting plastic, so that the card slot is illuminated.
Size of labelling field: 59.7 x 11.7 mm. Protection class (Device): IP 20
Protection class (Device): IP 20 anthracite 1792-81 2CKA001710A3639 10
anthracite 1764 NLI/KI-81 2CKA001731A3998 10/100
studio white 1792-84 2CKA001710A3641 10
studio white 1764 NLI/KI-84-500 2CKA001731A4002 10/100 black matt ) 1 1792-885 2CKA001710A3905 10
3
black matt ) 1764 NLI/KI-885 2CKA001731A4005 10/100 1) Surface painted.
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
2) Illumination using neon lamp 8353 or incandescent lamp 8344-1 and LED inserts.
3) Surface painted. Switch rocker with marking
For flush-mounted switch 1g1w, 1g2w, intermediate,
push switch.
Switch rocker with marking DO NOT DISTURB
with small red spherical cap Protection class (Device): IP 20
With imprint "0" and "I".
As cover for 2-pole or 3-pole flush-mounted on-off
switch and 2-pole control on-off switch. anthracite 1786/11-81 2CKA001751A3207 10
Protection class (Device): IP 20 studio white 1786/11-84 2CKA001751A2998 10
anthracite 1788-81 2CKA001751A2927 10 black matt ) 1 1786/11-885 2CKA001751A3040 10
studio white 1788-84 2CKA001751A2750 10/100 1) Surface painted. 11
black matt ) 1788-885 2CKA001751A3042 10
1
1) Surface painted. Switch rocker with marking
For flush-mounted switch 2g 1w, 2g push switch.
DO NOT DISTURB
Switch rocker with marking MAKE UP ROOM
with small red spherical cap Protection class (Device): IP 20
With marking "Heizung".
As cover for flush-mounted 1gang 1way, 1gang 2way
switch, intermediate switch, push-button and control anthracite 1785/11-81 2CKA001751A3205 10
switch 1gang 2way. studio white 1785/11-84 2CKA001751A2992 10
As cover for 2-pole or 3-pole flush-mounted on-off
switch and 2-pole control on-off switch. black matt ) 1 1785/11-885 2CKA001751A3037 10
Protection class (Device): IP 20 1) Surface painted.
anthracite 1789 H-81 2CKA001751A2929 10
studio white 1789 H-84 2CKA001751A2751 10 Bell push-switch DND/MUR
with marking "Do not Disturb" and "Make up Room"
black matt ) 1789 H-885 2CKA001751A3043 10
1
two seperate LED indicators
with screw-type terminal
1) Surface painted.
Rated voltage: 250 V~
Rated current: 10 ABS EN 60669-1, IEC 60669-1
Card switch 10 A )
1
SP, with normally open contact (operating current) delivery on request
Illuminable. anthracite 2029 UC-81 2CKA001751A3167 1
With N terminal.
Rated voltage: 250 V~ studio white 2029 UC-84 2CKA001751A3170 1
Rated current: 10 A black matt ) 1 2029 UC-885 2CKA001751A3173 1
Protection class (Device): IP 20IEC60669-1, British
1) Surface painted.
Standard EN 60669-1
2025 U 2CKA001012A1713 10
Pull switch ) 1
Mounting 35 mm deep flush 1gang SP, with normally open contact (operating current)
boxes: or Dual Box 3070-2/35 BSDB. With 2-metre pull cord, red handle, and red neon
2gang product 2gang combination with adapter plate indicator.
combinations: APBS in Dual Box only. Rated voltage: 250 V~
Rated current: 10 A
delivery form: Adapter plate APBS to be ordered separate.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073, 2020/01 US-101 2CKA001413A1112 10
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall 1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
or 3060 wallbox concrete)
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
