Busch-axcent®
Dimmers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
3
Friends of Hue smart switch insert Busch-rotary dimmer ) ) ) ) ) ) )
1
4
7
6
5
Wall-mounted transmitter, 2 channel UP, LED, 2-400 W
For Friends of Hue smart switch rocker 6736 FoH-8xx. Very small installation depth: < 20 mm
Smart light switch for wireless remote control of Philips Without claws.
Hue lamps. For switching/dimming of Philips Hue With rotary control, two-way switch and soft-catch.
lamps. For storing, recalling and dimming of max. 2 2-wire connection (neutral conductor not required)
individual light scenes. Battery-free and maintenance- Optimised for dimming of retrofit LED lamps (LEDi).
free thanks to "Energy Harvesting". For dimmable Retrofit-LEDs (LEDi).
Maximum reliability due to Zigbee Mesh technology. For dimmable Retrofit-LEDs (LEDi) with conventional or
Requires Philips Hue Bridge v2 (square shape) and the electronic transformers.
latest Philips Hue app (v3.2 or later). For incandescent lamps, 230 V tungsten halogen
Can be combined with switch ranges carat®, Busch- lamps, low-voltage halogen lamps with conventional or
dynasty®, pure stainless steel, solo®, Busch-axcent® and electronic transformers and dimmable energy-saving
future® linear. Can be freely mounted in the room using halogen lamps.
the enclosed adhesive tape and mounting plate. Mix operaton of LEDi with conventional loads possible.
Including fixing plate for mounting on smooth walls With manually adjustable operating mode: trailing /
or on switch boxes. Including mounting components: leading edge control.
Double-sided tape + decorative sticker. With adjustable minimum/maximum brightness.
Low-noise level by MOSFET transistors.
6716 U-500 2CKA006710A0014 1
With electronic short-circuit protection.
With electronic overload protection.
Rocker Without cover plate.
For Friends of Hue smart switch insert 6716 U-500. Rated voltage: 230 V~, + 10% / - 10%
Can be combined with switch ranges carat®, Busch- Rated frequency: 50 Hz/60 Hz
dynasty®, pure stainless steel, solo®, Busch-axcent® and Nominal power: 2 - 100 W/VA (leading edge control)
future® linear. Nominal power: 2 - 400 W/VA (trailing edge control) 11
Protection class (Device): IP 20
Temperature range (Device): 0 °C to 35 °CIEC 60669-2-1,
studio white 6736 FoH-84 2CKA006730A0136 1 British Standard EN 60669-2-1

Busch-rotary dimmer ) ) ) ) ) ) )
6
7
4
5
1
2
3
Flush-mounted, LED, 2-100 W 6523 UR-103-500 2CKA006512A0345 1/10
With rotary control, two-way switch and soft-catch. 1) Illuminable with neon lamp. Neon lamp included in delivery with cover plate.
2-wire connection (neutral conductor not required) 2) In the case of conventional transformers, take ~20% transformer loss into account.
Optimised for dimming of retrofit LED lamps (LEDi). 3) In case of electronic transformers, 5 % transformer losses.
For dimmable Retrofit-LEDs (LEDi). 4) Also applicable for 1gang 2way installations.
For dimmable Retrofit-LEDs (LEDi) with conventional 5) Provided with terminal for net disconnection devices.
6) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
or electronic transformers. For incandescent lamps, Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
230 V tungsten halogen lamps, low-voltage halogen or 3060 wallbox concrete)
lamps with conventional or electronic transformers and 7) Recommendation: Please use loads and types of one producer.
dimmable energy-saving halogen lamps.
Mix operaton of LEDi with conventional loads possible.
Via mode switch adjustable between leading edge
control and trailing edge control.
Low-noise level by MOSFET transistors.
With electronic short-circuit protection.
With electronic overload protection.
With adjustable minimum brightness.
Without cover plate.
Rated voltage: 230 V~, + 10% / - 10%
Rated frequency: 50 Hz/60 Hz
Nominal power: 2 - 100 W/VA (retrofit LED loads).
Nominal power: 10 - 250 W/VA (non-LED loads).
Protection class (Device): IP 20
Temperature range (Device): 0 °C to 35 °CIEC 60669-2-1,
British Standard EN 60669-2-1

6523 U-102-500 2CKA006512A0335 1/10
1) Illuminable with neon lamp. Neon lamp included in delivery with cover plate.
2) In the case of conventional transformers, take ~20% transformer loss into account.
3) In case of electronic transformers, 5 % transformer losses.
4) Also applicable for 1gang 2way installations.
5) Provided with terminal for net disconnection devices.
6) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
7) Recommendation: Please use loads and types of one producer.
