Busch-axcent®
Rocker switches / push switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

1
Rocker Switch Mechanism, control ) ) ) Push-switch mechanism )
2
1
3
With neon lamp. With one input terminal and 2 actuating covers.
Rated voltage: 250 V~ Rated voltage: 250 V~
Rated current: 10 AX Inputs: 1
Protection class (Device): IP 20 Outputs: 2x Normally open contact
IEC 60669-1 Rated current: 10 A
Protection class (Device): IP 20IEC 60669-1
1gang 2way with N-terminal 2020 US-205-500 2CKA001413A1105 10/100
2000/6 USK-500 2CKA001022A0659 10/100 1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
DP, 1gang 1way or 3060 wallbox concrete)
2000/2 UK 2CKA001022A0656 10
1
1) With 1 mA neon lamp. Push-switch mechanism )
2) Only in conjunction with standard flush-mounting boxes according to DIN 49073, SP, 1gang 2way
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall Can be wired for normally open contacts (stand-by
or 3060 wallbox concrete) current) or normally closed contacts (operating current).
3) Illuminable by using lamps 8360, 8362, 8363, 8365, 8366, and 8367 and LED inserts.
With N terminal.
Rated voltage: 250 V~
Rated current: 10 A
2
3
Rocker Switch Mechanism, control ) ) ) Protection class (Device): IP 20IEC 60669-1
1
1gang 2way with N-terminal
With neon lamp. 2020 US-206-500 2CKA001413A1104 10/100
Rated voltage: 250 V~ 1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Rated current: 16 AX Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
Protection class (Device): IP 20IEC 60669-1 or 3060 wallbox concrete)
11
2400/6 USK-500 2CKA001022A0661 10
Rocker
1) With 1 mA neon lamp.
For flush-mounted switch 1g1w, 1g2w, intermediate,
2) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall push switch.
or 3060 wallbox concrete) Protection class (Device): IP 20
3) Illuminable by using lamps 8360, 8362, 8363, 8365, 8366, and 8367 and LED inserts.
Push-switch mechanism ) 1 anthracite 1786-81 2CKA001751A2926 10/100
SP, with normally open contact (operating current)
With N terminal. studio white 1786-84-500 2CKA001751A3074 10/100
Rated voltage: 250 V~ black matt ) 1 1786-885 2CKA001751A3041 10/100
Rated current: 10 A 1) Surface painted.
Protection class (Device): IP 20IEC 60669-1
2020 US-500 2CKA001413A0574 10/100 Rocker
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073, For flush-mounted switch 2g 1w, 2g push switch.
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall Protection class (Device): IP 20
or 3060 wallbox concrete)
Push-switch mechanism )
1
SP, with normally open contact (operating current) anthracite 1785-81 2CKA001751A2930 10
With 2 independent signalling contacts. studio white 1785-84-500 2CKA001751A3076 10/100
Rated voltage: 250 V~
Inputs: 1, Outputs: 1, Rated current: 10 A black matt ) 1 1785-885 2CKA001751A3038 10/100
Protection class (Device): IP 20IEC 60669-1 1) Surface painted.
2020 US-201 2CKA001413A0483 10
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073, Rocker
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall As a cover for flush-mounted control 2gang switch.
or 3060 wallbox concrete) Protection class (Device): IP 20

Push-switch mechanism ) ) )
1
2
3
SP, with normally open contact (operating current)
With illumination. With N terminal. anthracite 1785 K-81 2CKA001751A3121 10
Rated voltage: 250 V~ studio white 1785 K-84-500 2CKA001751A3128 10
Rated current: 10 A
Protection class (Device): IP 20IEC 60669-1 black matt ) 1 1785 K-885 2CKA001751A3136 10
1) Surface painted.
2020 USGL-500 2CKA001413A1106 10/100
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
2) Replacement lamps 8360, 8362, and 8363 and LED inserts.
3) For relay and touch dimmer applications.
