Busch-axcent®
Rocker switches / push switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Pull switch ) 1 Cover plate
SP, break contact with rotary control, with marking
With 2-metre pull cord, red handle, and red neon As cover for flush mounted three-step rotary switch.
indicator. With zero position.
Rated voltage: 250 V~ For insert 2710 U.
Rated current: 10 A Protection class (Device): IP 20
2020/10 US-101 2CKA001413A1111 10 anthracite 2542 DR/01-81 2CKA001710A3644 10
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073, studio white 2542 DR/01-84 2CKA001710A3646 10
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall 1
or 3060 wallbox concrete) black matt ) 2542 DR/01-885 2CKA001710A3913 10
1) Surface painted.
Cover plate ) 1
for pull switch 2610/6 UC-xx, 2610/6 UJ-xx Cover plate
With screw-type terminal with rotary control, with marking
Protection class (Device): IP 20 As cover for flush mounted three-step rotary switch.
Without zero position.
For insert 2710/1 U.
Protection class (Device): IP 20
anthracite 1796-81 2CKA001753A0308 10
anthracite 2542 DR/02-81 2CKA001710A3649 10
studio white 1796-84 2CKA001753A0311 10
black matt ) 1796-885 2CKA001753A0314 10 studio white 2542 DR/02-84 2CKA001710A3651 10
2
black matt ) 1 2542 DR/02-885 2CKA001710A3914 10
1) Exchanging the available cover/cover plate.
2) Surface painted. 1) Surface painted.
11
Rocker
open for red pull switch neon indicator
For pull switch 2020/xx US.
Protection class (Device): IP 20

anthracite 1720-81 2CKA001731A1914 10
studio white 1720-84 2CKA001731A1916 10
1
black matt ) 1720-885 2CKA001731A1981 10
1) Surface painted.

1
2
Three-step rotary switch ) )
SP, with zero position
With zero position.
Rated voltage: 250 V~
Rated current: 16 A
Protection class (Device): IP 20
2710 U 2CKA001101A0918 1/10
1) Install only in conjunction with wall boxes ø 60 mm.
2) Not to be mounted in SM box 1701-xxx, 1702-xxx, 1703-xxx.

1
2
Three-step rotary switch ) )
SP, without zero position
Without zero position.
Rated voltage: 250 V~
Rated current: 16 A
Protection class (Device): IP 20
2710/1 U 2CKA001101A0919 1/10
1) Install only in conjunction with wall boxes ø 60 mm.
2) Not to be mounted in SM box 1701-xxx, 1702-xxx, 1703-xxx.
