11/208 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Busch-axcent®
Multimedia / communication adapters Room thermostats

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Cover plate Room thermostat, flush-mounted ) ) ) 3
2
1
For USB charging station 6474 U. Switch contact opens when the set temperature is
With protective function against lateral slipping of the reached.
mobile telephone. With fixing claws.
Suitable for devices with a maximum thickness of 18 Separate terminal to activate nighttime mode and
mm. reduction of room temperature by 4K.
With frontal mounting option of connecting cable. Class of temperature controller 1
Contribution to space heating energy efficiency 1,0%.
anthracite 6478-81-500 2CKA006400A0013 1
Rated voltage: 230 V~
studio white 6478-84-500 2CKA006400A0019 1 Rated current: 10 A
black matt ) 6478-885-500 2CKA006400A0029 1 Temperature range (Device): 5 °C to 30 °CEN 60730-2-9,
1
British Standard EN 60669-2-1
1) Surface painted.
1094 U-500 2CKA001032A0512 1/10
Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB.
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
2) Servo-valves, "closed when de-energized", are necessary for connection to
thermostat. e.g. Article No. 6164/10-, see KNX chapter.
3) Switching temperature difference: ± 0.5 K.
Room thermostat, flush-mounted ) ) ) 3
1
2
11
Slide switch
With built-in slide switch and control lamp for nightly
reduction of 4 K.
Switch contact opens when the set temperature is
reached.
With fixing claws.
Separate terminal to activate nighttime mode and
reduction of room temperature by 4K.
Class of temperature controller 1
Contribution to space heating energy efficiency 1,0%.
Rated voltage: 230 V~
Rated current: 10 A
Temperature range (Device): 5 °C to 30 °CEN 60730-2-9,
British Standard EN 60669-2-1
1095 U-500 2CKA001032A0514 1/10
Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB.
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
2) Servo-valves, "closed when de-energized", are necessary for connection to
thermostat. e.g. Article No. 6164/10-, see KNX chapter.
3) Switching temperature difference: ± 0.5 K.
