Busch-axcent®
LED light WaveLINE control elements

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
Cover plate ) ) Wall-mounted transmitter WaveLINE ) )
2
1
1
As cover for flush-mounted info light. 1-channel
For insert 2062 U. 1gang wall-mounted transmitter independent of mains
Size of information field 43 x 43 mm. power supply.
Protection class (Device): IP 20 With labelling field and labelling strip.
For switching and dimming.
For controlling blinds and light scenes.
anthracite 1716-81 2CKA001731A1921 1 1 radio channel can be operated or up to 2 light scenes
studio white 1716-84 2CKA001731A1923 1 can be called up.
For flush-mounted WaveLINE actuators 6701-101, 6702,
black matt ) 1716-885 2CKA001731A1980 1
3
6703, 6704 and 6705-101.
1) Included with the cover are 46 different text labels and symbols.
For LED display WaveLINE 6730-xxx.
2) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
Compatible with WaveLINE KNX gateway TP-RF 6770.
3) Surface painted.
Send frequency: 868 MHz.
Free-field range: approx. 100 m.
Cover plate Power supply: lithium button cell battery Type CR2032.
for indication lamp Battery service life: typically 5 years, therefore
For insert 2061/2661 U. practically maintenance-free.
As cover for flush-mounted light signal. Automatic monitoring of battery life.
Protection class (Device): IP 20 Including fixing plate for mounting on smooth walls or
on switch boxes.
Control element: rocker switch left/right
anthracite 1756-81 2CKA001753A0089 10 Display elements: LED to indicate the transmission
studio white 1756-84 2CKA001753A0092 10 Rated voltage: 3 V-
Protection class (Device): IP 20
black matt ) 1756-885 2CKA001753A0252 10 Temperature range (Device): -5 °C to 45 °C
1
Dimensions: (L x W x D): 63 mm x 63 mm x 16 mm
1) Surface painted.
11
studio white 6731-84-500 2CKA006730A0038 1/10
Cap 1) Battery included in delivery.
for indication lamp 2) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
For indication lamps.
Protection class (Device): IP 20
Wall-mounted transmitter WaveLINE ) )
2
1
2-channel
2gang wall-mounted transmitter independent of mains
clear- 1565-11 2CKA001565A0167 10 power supply.
transparent With labelling field and labelling strip.
Red 1565-12 2CKA001565A0175 10 For switching and dimming.
For controlling blinds and light scenes.
green 1565-13 2CKA001565A0183 10 2 radio channels can be operated or up to 4 light scenes
can be called up.
For flush-mounted WaveLINE actuators 6701-101, 6702,
6703, 6704 and 6705-101.
For LED display WaveLINE 6730-xxx.
Compatible with WaveLINE KNX gateway TP-RF 6770.
Send frequency: 868 MHz.
Free-field range: approx. 100 m.
Power supply: lithium button cell battery Type CR2032.
Battery service life: typically 5 years, therefore
practically maintenance-free.
Automatic monitoring of battery life.
Including fixing plate for mounting on smooth walls or
on switch boxes.
Control element: rocker switch left/right
Display elements: LED to indicate the transmission
Rated voltage: 3 V-
Protection class (Device): IP 20
Temperature range (Device): -5 °C to 45 °C
Dimensions: (L x W x D): 63 mm x 63 mm x 16 mm
studio white 6732-84-500 2CKA006730A0039 1/10
1) Battery included in delivery.
2) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
