future® linear
Dimmers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
5
Busch-2gang switch/rotary dimmer ) ) ) Busch-rotary dimmer ) ) ) ) ) )
3
4
2
3
1
6
1
flush mounted, RL, 60-400 W flush mounted, RC, 40-420 W
1 channel designed as dimmer. DP switched
1 channel designed as switch contact (1gang 2way With rotary control, soft-catch and with trailing edge
contact element) control. For incandescent lamps, 230 V tungsten
with leading edge control halogen lamps and low-voltage halogen lamps with
For incandescent lamps, 230 V tungsten halogen electronic transformers. Low-noise, short-circuit-proof,
lamps and low-volt halogen lamps with conventional overload-protected. Without cover plate.
transformer. DP cut off (P,N)
With adjustable minimum brightness. Rated voltage: 230 V~, +10 % / -10 %
Without cover plate. Rated frequency: 50 Hz
Rated current 6A (changeover contact switch output). Rated power: 20 - 420 W/VA
Rated voltage: 230 V~, +10 % / -10 % IEC 60669-2-1, British Standard EN 60669-2-1
Rated frequency: 50 Hz
Rated power: 60 - 400 W/VA
IEC 60669-2-1, British Standard EN 60669-2-1 6514 U-500 2CKA006514A0115 1
1) Not suitable with conventional transformers.
2) Illuminable with neon lamp. Neon lamp included in delivery with cover plate.
6517 U-101-500 2CKA006517A0018 1/10 3) In case of electronic transformers, 5 % transformer losses.
4) Provided with terminal for net disconnection devices.
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
5) Also applicable for 1gang 2way installations.
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall 6) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
or 3060 wallbox concrete)
2) In the case of conventional transformers, take ~20% transformer loss into account. Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
3) Can be used to replace a 2gang 1way switch. or 3060 wallbox concrete)
1
4
2
3
5
2
5
6
3
4
1
Busch-rotary dimmer ) ) ) ) ) ) Busch-rotary dimmer ) ) ) ) ) 11
flush mounted, RC, 40-420 W flush mounted, RLC, 60-420 W
With rotary control, soft-catch and with trailing edge with soft-catch
control. With intelligence for universal operation.
For incandescent lamps, 230 V tungsten halogen For incandescent lamps, 230 V tungsten halogen lamps
lamps and low-voltage halogen lamps with electronic and low-voltage halogen lamps with conventional
transformers. transformers or electronic transformers.
Low-noise, short-circuit-proof, overload-protected. Short-circuit-proof, overload-protected.
Without cover plate. Capacity expansion via output-side, parallel connectable
Rated voltage: 230 V~, +10 % / -10 % load line with a power module 6594 U up to 735 W/VA
Rated frequency: 50 Hz possible. Operation via rotary-type remote control
Rated power: 40 - 420 W/VA 6592 U possible. Without cover plate.
IEC 60669-2-1, British Standard EN 60669-2-1 Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz - 60 Hz
Rated power: 60 - 420 W/VA
IEC 60669-2-1, British Standard EN 60669-2-1
6513 U-102-500 2CKA006513A0586 1/10
1) Not suitable with conventional transformers.
2) Illuminable with neon lamp. Neon lamp included in delivery with cover plate.
3) In case of electronic transformers, 5 % transformer losses. 6591 U-101-500 2CKA006513A0588 1/10
4) Provided with terminal for net disconnection devices. 1) Illuminable with neon lamp 3855. Neon lamp included in delivery with cover plate.
5) Also applicable for 1gang 2way installations. 2) In case of electronic transformers, 5 % transformer losses.
6) Only in conjunction with standard flush-mounting boxes according to DIN 49073, 3) In the case of conventional transformers, take ~20% transformer loss into account.
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall 4) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
or 3060 wallbox concrete) Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
5) Cannot be combined with a 2way switch.
Busch-rotary dimmer, extension ) )
1
2
flush mounted
for connection to 6591 U-101,
To be used with Busch-Dimmer®, MDRC 6583.
with soft-catch. A maximum of 5 multi-way extensions
can be connected to a 6591U-101. Without cover plate.
Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz - 60 Hz

6592 U-500 2CKA006513A0590 1
1) Control elements 2115-xxx and 6540-xxx.
2) Required for illuminating the N-connection control element.
