future® linear
Dimmers Movement detectors / comfort switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Control element ) ) ) Busch-Universal relay switch insert
1
2
3
with neon lamp 3 wire connection (neutral conductor required).
Can be combined with LED dimmer 6524 U, and 6526 U, For Busch-Watchdog 180 flush-mounted Sensor
Busch-Universal touch-type controller 6550 U-10x, Standard 6810-21x-101.
Busch-Memory touch dimmer 6560 U-101, Busch- For Busch-Watchdog 180 flush-mounted sensor
Universal-Dimmer® 6593 U, Busch-Universal relay insert Comfort II 6800-xxx-104 and 6800-xxx-104M.
6401 U-10x, Busch-Universal 2gang insert 6402 U. For Busch-Watchdog 180 FP sensor for All Weather 44
6800-3x-102C. For Busch-Watchdog Presence tech 6813-
anthracite 6543-81-101 2CKA006599A2881 1/10
xxx-101 und 6813/11-xxx.
ivory white 6543-82-101 2CKA006599A2831 1/10 For comfort timer control element 6455-101-500.
aluminium 6543-83-101 2CKA006599A2887 1/10 For Busch-Remote control IR control cover 6067-xxx-10x.
silver ) For control cover with control lamp 6543-xxx-10x.
4
Combinable with Busch-Watchdog extension insert
studio white 6543-84-101-500 2CKA006599A3010 1/10
6805 U. Operation also possible via conventional push
studio white, 6543-884-101 2CKA006599A2963 1/10 buttons (2020 US, 2021/6 UK).
matt ) Rated voltage: 230 V~, +10 % / -10 %
4
black matt ) 6543-885-101 2CKA006599A2968 1/10 Rated frequency: 50 Hz
4
Outputs: 1x Normally open contact, potential-bound
1) Compatible with previous type 6543-xxx.
2) Touch-type Controller 6550 U-xxx non-illuminable. Suitable for: 230 V incandescent lamps, 230 V halogen
3) Replacement neon lamp 3857. lamps, fluorescent lamps and low-voltage halogen
4) Surface painted. lamps, that are operated via transformers.
Rated current: 10 AX
Rated power: 2300 W/VA
1
Control element )
with neon lamp Temperature range (Device): -25 °C to 55 °C60669-2-1
Combinable with Busch-Memory 2gang dimmer 6565 U.
11
6401 U-102-500 2CKA006401A0049 1/10
anthracite 6545-81 2CKA006599A2906 1/10 Busch-Universal 2gang 1way insert
3 wire connection (neutral conductor required).
ivory white 6545-82 2CKA006599A2907 1/10 For the serial switch operating mode: 2 separate
aluminium 6545-83 2CKA006599A2914 1/10 outputs, 2 separate extension inputs.
2
silver ) For operation mode timer: output 1 (eg lighting),
studio white 6545-84 2CKA006599A2908 1/10 output 2: ON/Off delay in dependence of output 1 (eg
fan control). For Busch-Watchdog 180 flush-mounted
studio white, 6545-884 2CKA006599A2964 1/10 Sensor Standard 6810-21x-101.
2
matt ) For Busch-Watchdog 180 flush-mounted sensor
black matt ) 6545-885 2CKA006599A2969 1/10 Comfort II 6800-xxx-104 and 6800-xxx-104M.
2
For Busch-Watchdog Presence tech 6813-xxx-101 und
1) Replacement neon lamp 3857.
6813/11-xxx. For Busch-Remote control IR control cover
2) Surface painted.
6066-xxx-10x and 6067-xxx-10x.
For control cover 6430-xxx-10x and 6543-xxx-10x.
Cover plate Combinable with Busch-Watchdog extension insert
for cooling element 6805 U. Operation also possible via conventional push
For Busch-Universal master dimmer power module buttons (2020 US, 2021/6 UK).
6594 U. Rated voltage: 230 V~, +10 % / -10 %
For room temperature controller object range 6108/0x Rated frequency: 50 Hz
and base for blind cover 6930/01. Outputs: 2x Normally open contact, potential-bound
Suitable for: 230 V incandescent lamps, 230 V halogen
anthracite 6541-81 2CKA006599A2882 10 lamps, fluorescent lamps and low-voltage halogen
ivory white 6541-82 2CKA006599A2832 10 lamps, that are operated via transformers.
Rated current: 10 AX
aluminium 6541-83 2CKA006599A2885 10
1
silver ) Rated power: 2300 W/VA
studio white 6541-84 2CKA006599A2835 10 Temperature range (Device): 0 °C to 35 °CBritish
studio white, 6541-884 2CKA006599A2962 10 Standard EN 60669-2-1
1
matt )
1
black matt ) 6541-885 2CKA006599A2967 10 6402 U-500 2CKA006401A0051 1/10
Mounting 35 mm deep flush 1gang
1) Surface painted.
boxes: or Dual Box 3070-2/35 BSDB.
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
neon indicator: neon lamp 3855, one neon lamp is supplied together with
control cover plates 6540-2x.
