11/258 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
future® linear
Multimedia / communication adapters

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Loudspeaker insert ) Busch-powerDock Charging cradle with USB-C
1
5 cm (2") connection
For Busch-DigitalRadio 8215 U/8216 U. For Busch-powerDock insert 6473 U.
For Busch-Radio iNet 8216 U. For attaching mobile terminal devices with USB-C
For Busch-Radio BTconnect 8217 U. connection.
For Busch Bluetooth receiver 8219 U. Temperature range (Device): 5 °C to 35 °C
With broadband characteristics. Dimensions: (L x W x D): 54 mm x 54 mm x 36 mm
With flat plug connector. 6473/11-500 2CKA006400A0083 1/10
Incl. speaker connection cable.
Rated output: 2 W (RMS)
Frequency response: 200 - 20,000 Hz USB charging station insert ) ) )
2
3
1
Impedance: 4 Ohm For supply and support of mobile devices via USB-cable.
Protection class (Device): IP 20, SELV With micro USB connecting cable.
Mounting depth: 32 mm Connecting cable joined captive to insert.
8223 U-500 2CKA008200A0183 1/10 Usable cable length (incl. micro USB plug) approx.
22 cm.
1) No claw. Screw-fixing via keyholes.
With electronic short-circuit protection.
With electronic overload protection.
Busch-powerDock Insert ) ) ) ) Rated voltage: 100 - 230 V~, +10 % / -10 %
3
4
2
1
For charging and supplying mobile terminal devices. Secondary: 5 V-, +5 % / -5 %
With quick charging function for devices compatible Rated frequency: 50 Hz - 60 Hz
with quick-chargeTM. Rated current: 1400 mA
Makes possible fast charging of the mobile terminal Protection class (Device): IP 20, SELV
device. Temperature range (Device): 5 °C to 40 °C
Rated voltage: 100 - 230 V~, +10 % / -10 % Dimensions: (L x W x D): 71 mm x 71 mm x 35 mm
Rated frequency: 50 Hz - 60 Hz Mounting depth: 32 mm
Suitable for: Apple terminal device 6474 U-500 2CKA006400A0033 1/10
11
Rated current: 2.1 A 1) No claw. Screw-fixing via keyholes.
Output voltage: 5 V- 2) No data transfer.
Suitable for: Terminal device with USB-C connection 3) For terminal devices with standardized charging interface according to DIN EN
Rated current: 2.1 A 62684.
Output voltage: 5 V-
Suitable for: Terminal device with quick-charge support
1
2
4
3
and USB-C connection and quick-charge TM function. USB power adapter insert, flush-mounted ) ) ) )
Rated current: 2 A For supply and support of mobile devices via USB-cable.
Output voltage: 9 V- With two USB type A outputs.
Protection class (Device): IP 20, SELV To support two devices at the same time.
Temperature range (Device): 5 °C to 35 °C With electronic short-circuit protection.
Dimensions: (L x W x D): 71 mm x 71 mm x 32 mm With electronic overload protection.
Mounting depth: 32 mm Rated voltage: 100 - 230 V~, +10 % / -10 %
Secondary: 5 V-, +5 % / -5 %
6473 U-500 2CKA006400A0039 1/10
Rated frequency: 50 Hz - 60 Hz
1) No claw. Screw-fixing via keyholes. Suitable for: In case one output is used:
2) The USB-C connection of the Busch-powerDock uses the quick charging function Rated current: 1400 mA
according to Qualcomm® Quick chargeTM 2.0 standard. Suitable for: In case two output are used:
3) In rare cases the manufacturers of USB-C terminal devices support the quick-
charging function independent of this standard only in case of charging devices Rated current: 700 mA
that are the same as those of other manufacturers. Protection class (Device): IP 20, SELV
4) In these cases the quick-charging function of the terminal device is not enabled. Temperature range (Device): 5 °C to 40 °C
Dimensions: (L x W x D): 71 mm x 71 mm x 43 mm
Mounting depth: 32 mm
Busch-powerDock Charging cradle with Apple lightning
connection ) 6472 U-500 2CKA006400A0002 1
1
For Busch-powerDock insert 6473 U. 1) No claw. Screw-fixing via keyholes.
For attaching mobile terminal devices with lightning 2) No data transfer.
connection. 3) For terminal devices with standardized charging interface according to DIN EN
62684.
For iPhone XS Max, iPhone XS, iPhone XR, iPhone X. 4) Use dust cover 2098 when cleaning the device.
For iPhone 8 Plus, iPhone 8.
For iPhone 7 Plus, iPhone 7.
For iPhone SE.
For iPhone 6s Plus, iPhone 6s, iPhone 6 Plus, iPhone 6.
For iPhone 5s, iPhone 5c, iPhone 5.
For iPod touch (6th generation), iPod touch (5th
generation), iPod nano (7th generation).
Suitable for use with protective covers certified by
Apple.
Temperature range (Device): 5 °C to 35 °C
Dimensions: (L x W x D): 54 mm x 54 mm x 36 mm
6473-500 2CKA006400A0081 1/10
1) Not released for use with the iPad.
