11/276 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
basic55®
Selected functions.

01 02 03 04 05 06 07

08 09 10 11 12 13 14

15 16 17 18 19 20 21

22 23 24 25 26 27 28
11

01 Switch/button with rocker 16 Comfort timer
02 2gang switch 17 Card switch
03 2gang switch with neon lamp 18 Room temperature controller
04 3gang 1way switch 19 Antenna socket
05 Push switch with doorbell symbol and labeling field 20 Antenna socket for TV
06 Rotary dimmer 21 Antenna socket for Radio/TV/SAT
07 Push switch with illumination 22 Light signal
08 20 A DP switch with red neon indicator 23 Busch-iDock
09 Busch-Comfort switch® 24 Loudspeaker outlet
10 SCHUKO® socket outlet, shuttered 25 Telephone Single Outlet (TAE)
11 Socket outlet, shuttered with earthing pin 26 Universal data connecting unit
12 SCHUKO® socket outlet with hinged lid 27 Universal data connecting unit, 2gang
13 SCHUKO® double socket outlet 28 Loudspeaker
14 Blind switches/push-buttons
15 Blind switches/push-buttons with rotary knob
