11/316 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Sky Niessen
Key switches Blind controls

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Key switch 1-way, 2 positions, single pole Push-button blind control 2-gangs
Rated voltage: 110 - 250 Vac. Rated voltage: 110 - 250 Vac.
Rated current: 5 A. Rated current: 10 AX.
Key removable in the 2 positions. Direct control.
Unique key for each lock. Interlocked gangs.
Suitable for alarms. Included: fixing claws.
Cover plate code: 8553. Rocker code: 8544.

8153 2CLA815300A1001 1 8144 2CLA814400A1001 10

Key push button 1-way, 2 positions, SP Switch blind control 2-gangs
Rated voltage: 110 - 250 Vac. Rated voltage: 110 - 250 Vac.
Rated current: 5 A. Rated current: 10 AX.
Key removable in “OFF” position. Direct control.
Unique key for each lock. Interlocked gangs.
Suitable for alarms. Included: fixing claws.
Cover plate code: 8553. Rocker code: 8544.
8153.2 2CLA815320A1001 1 8144.1 2CLA814410A1001 10

Cover plate for 2 position key switch Rocker for blind switch/push-button
Cover plate for key switch code: 8153 & 8153.2. Rocker for blind switch/push-button code:
8144 & 8144.1.

11
Soft White 8553 BL 2CLA855300A1101 1
Soft White 8544 BL 2CLA854400A1101 10
Silver 8553 PL 2CLA855300A1301 1
Silver 8544 PL 2CLA854400A1301 10
Soft Black 8553 NS 2CLA855300A1501 1
Soft Black 8544 NS 2CLA854400A1501 10
Stainless Steel 8553 AI 2CLA855300A1401 1
Stainless Steel 8544 AI 2CLA854400A1401 10
Antique Gold 8553 OE 2CLA855300A1201 1
Antique Gold 8544 OE 2CLA854400A1201 10
White Glass 8544 CB 2CLA854400A2101 5
Key switch 2-way, 3 positions, single pole
Rated voltage: 110 - 250 Vac. Black Glass 8544 CN 2CLA854400A2501 5
Rated current: 150 mA.
Key removable in “OFF” position. Electronic blind control 1-gang
Unique key for each lock. Rated voltage: 110 - 250 Vac ; 50 / 60 Hz.
Suitable for blinds, shutters, etc. Rated current: 700VA@230Vac / 350VA@127Vac.
Cover plate code: 8553.1. Direct control.
Functions:
8153.1 2CLA815310A1001 1 - PERS: standard blinds control. Optionally other 8144
inserts can be connected to the 8130.3 to control the
blind from other locations.
Cover plate for 3 position key switch - LAM: venetian type blinds control. Optionally other 8144
Cover plate for key switch code: 8153.1. inserts can be connected to the 8130.3 to control the
blind from other locations.
- Centralization (CEN): one 8130.3 can control all the
8130.3 of a line centrally.
Included: fixing claws.
Electronic rocker code: 8530.
Soft White 8553.1 BL 2CLA855310A1101 1
8130.3 2CLA813030A1001 1
Silver 8553.1 PL 2CLA855310A1301 1
Soft Black 8553.1 NS 2CLA855310A1501 1 Electronic rocker for blind control
Stainless Steel 8553.1 AI 2CLA855310A1401 1 Electronic rocker for blind control code: 8130.3.
Antique Gold 8553.1 OE 2CLA855310A1201 1

Soft White 8530 BL 2CLA853000A1101 1
Silver 8530 PL 2CLA853000A1301 1
Soft Black 8530 NS 2CLA853000A1501 1
Stainless Steel 8530 AI 2CLA853000A1401 1
Antique Gold 8530 OE 2CLA853000A1201 1
