11/483

—
Zenit - workstations
Floor boxes Mounting plates for floor box

Color Article-No. Order-No. Pack/Qty Color Article-No. Order-No. Pack/Qty

Floor box - 3 columns - 5 mm. hollow lid Mounting plate for floor box - 3 columns
Floor box with 5 mm. deep hollow lid for carpet, linoleum, 3-column adapter for the installation of Zenit devices
etc. and/or T10XX devices in floor boxes code: T1393 and
Protection degree: T1393.1.
- IP52 between the box and the floor ensured by 3-columns - 2+2+2+2+2+2 modules.
loss-proof seal. For 1 or 2 module devices. Also suitable for T10XX
- IP4x at the rim of the lid. devices.
- IP2x at the cable inlet. Included:
Resistance of the lid: 1500 N according to DIN VDE 0364. - Mounting plates.
Resistance to chemicals present in the main detergents. - Frame.
Direct installation in technical or raised floor. Installation - Screws.
in tradiotional floors using the flush mounting metal box
code T1393.9. White T1373 2CLA137300T1101 20
Color: dark gray RAL 7021.
Size (height x width x depth): 235 x 300 x 100 mm.
Slot size (height x width): 211 x 275 mm. Adapter plate for floor box - 4 modules
Suitable mounting plates code: T1373 and T1371.4. 4 module adapter plate for the installation of Zenit
devices in floor boxes code: T1393 and T1393.1.
To be combined with Zenit 4-module mounting plates
code N1374.9 and frames code N2374.1.
For 1, 2 or 3 module devices.
Dark gray T1393 M109020000 1
Included: screws.
Floor box - 3 columns - Stainless steel lid Dark gray T1371.4 M109190000 6
Floor box with anti-slip square patterned lid with
stainless steel finish.
Protection degree: Duplex socket outlets 11
- IP52 between the box and the floor ensured by
loss-proof seal.
- IP4x at the rim of the lid. Duplex Schuko socket outlet
- IP2x at the cable inlet. Rated voltage: 250 Vac.
Resistance of the lid: 1500 N according to DIN VDE 0364. Rated current: 16A.
Resistance to chemicals present in the main detergents. Type F: 2P + E.
Direct installation in technical or raised floor. Installation Shuttered for child safety.
in tradiotional floors using the flush mounting metal box Screw terminals (common terminal for both outlets).
code T1393.9. Folding system for easy installation.
Color: dark gray RAL 7021. With labeling space.
Size (height x width x depth): 235 x 300 x 100 mm. Optional: power indicator LED lamp code: 6192.
Slot size (height x width): 211 x 275 mm. Suitable for boxes code T1193, T1194, T1195, T1093 and
Suitable mounting plates code: T1373 and T1371.4. T1094 and mounting plates code T1373.
Colors RJ and RP are suitable to identify special circuits.

Dark gray T1393.1 M109030000 1 White/White T1088 BL 2CLA108800T1001 5
Silver/Silver T1088 PL 2CLA108800T1301 5
Flush mounting metal box White/Red T1088 RJ 2CLA108800T7001 5
Accessory for the installation of the floor boxes code
T1393 and T1393.1 in tradiotional/concrete floors. Silver/Red T1088 RP 2CLA108800T7301 5
Supplied with protection semi-lid and bunkheads for
trunkings of 70x30 mm. and of 95x30 mm. and for ø 25 Duplex French/Earth-pin socket outlet
mm and 32 mm. conduits. Rated voltage: 250 Vac.
Size (height x width x depth): 230 x 305 x 105 mm. Rated current: 16A.
Type E: 2P + E.
Shuttered for child safety.
T1393.9 M109300000 1
Screw terminals (common terminal for both outlets).
Folding system for easy installation.
With labeling space.
Optional: power indicator LED lamp code: 6192.
Suitable for boxes code T1193, T1194, T1195, T1093 and
T1094 and mounting plates code T1373.
Color RJ is suitable to identify special circuits.

White/White T1087 BL 2CLA108700T1001 5
White/Red T1087 RJ 2CLA108700T7001 5
