11/478 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
Zenit
IP55 surface mounting kits IP55 surface mounting boxes

Color Article-No. Order-No. Pack/Qty Color Article-No. Order-No. Pack/Qty

Kit IP55 2-way switch - surface mounted Surface mounting box - IP55 - 2 modules
Kit with: Box for IP55 surface mounted installations.
- N3291: IP55 box for surface mounting - 1-gang - 2 1-gang - 2 modules.
modules. For 1 or 2 module devices.
- N2202 BL: 1-gang, 2-way / 127 - 250 Vac / 16 AX. Size (height x width x depth): 80 x 65 x 63 mm
Protection degree: IP55 (with lid closed). Color: gray RAL 7035
Color: white device / gray RAL 7035 box. Protection degree: IP55 (with lid closed).
Opening angle of the lid: 120°. Opening angle of the lid: 120°.
The lid allows operating the switch in closed position. The lid allows operating the switch in closed position.
Incoming with multi-diameter cone for tubes/cables max. Incoming with multi-diameter cone for tubes/cables max. Ø20.
Ø20. The box includes the clipping system to clasp inserts (no
The box includes the clipping system to clasp inserts (no mounting plate, nor frame are necessary).
mounting plate, nor frame are necessary).

Gray N3202 2CLA320200N1101 10 Gray N3291 2CLA329100N1101 10

Kit IP55 push button - surface mounted Surface mounting box - IP55 - 2+2 modules
Kit with: Box for IP55 surface mounted horizontal installations.
- N3291: IP55 box for surface mounting - 1-gang - 2 2-gang - 2+2 modules.
modules. For 1 or 2 module devices.
- N2204 BL: 1-gang, 1-way, NO push button / 127 - 250 Vac Size (height x width x depth): 80 x 130 x 63 mm.
/ 16 A. Color: gray RAL 7035.
Protection degree: IP55 (with lid closed). Protection degree: IP55 (with lid closed).
Color: white device / gray RAL 7035 box. Opening angle of the lid: 120°.
Opening angle of the lid: 120°. The lid allows operating the switch in closed position.
The lid allows operating the switch in closed position. Incoming with multi-diameter cone for tubes/cables max. Ø20.
11
Incoming with multi-diameter cone for tubes/cables max. The box includes the clipping system to clasp inserts (no
Ø20. mounting plate, nor frame are necessary).
The box includes the clipping system to clasp inserts (no
mounting plate, nor frame are necessary).
Gray N3292 2CLA329200N1101 10
Surface mounting box - IP55 - 2+2+2 modules
Gray N3204 2CLA300400N1101 10 Box for IP55 surface mounted horizontal installations.
3-gang - 2+2+2 modules.
Kit IP55 Schuko socket outlet - surface mounted For 1 or 2 module devices.
Kit with: Size (height x width x depth): 80 x 195 x 63 mm
- N3291: IP55 box for surface mounting - 1-gang - 2 Color: gray RAL 7035
modules. Protection degree: IP55 (with lid closed).
- N2288 BL: Schuko socket outlet / 127 - 250 Vac / 16 A. Opening angle of the lid: 120°.
Protection degree: IP55 (with lid closed). The lid allows operating the switch in closed position.
Color: white device / gray RAL 7035 box. Incoming with multi-diameter cone for tubes/cables max. Ø20.
Opening angle of the lid: 120°. The box includes the clipping system to clasp inserts (no
The lid allows operating the switch in closed position. mounting plate, nor frame are necessary).
Incoming with multi-diameter cone for tubes/cables max.
Ø20. Gray N3293 2CLA329300N1101 5
The box includes the clipping system to clasp inserts (no
mounting plate, nor frame are necessary). Surface mounting box - IP55 - 3 modules
Box for IP55 surface mounted horizontal installations.
1-gang - 3 modules.
For 1, 2 or 3 module devices.
Gray N3288 2CLA308800N1101 10 Size (height x width x depth): 80 x 104 x 63 mm.
Color: gray RAL 7035.
Protection degree: IP55 (with lid closed).
Opening angle of the lid: 120°.
The lid allows operating the switch in closed position.
Incoming with multi-diameter cone for tubes/cables max. Ø20.
The box includes the clipping system to clasp inserts (no
mounting plate, nor frame are necessary).

Gray N3391 2CLA339100N1101 10
