11/481

—
Zenit - workstations
Surface mounting boxes Flush mounting boxes

Color Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Surface mounting box - 3 columns Flush mounting box - 3 columns
Zenit workstation box for surface mounted Zenit workstation box for flush mounted installations.
installations. 3-columns - 2+2+2+2+2+2 modules.
3-columns - 2+2+2+2+2+2 modules. For 1 or 2 module devices. Also suitable for T10XX
For 1 or 2 module devices. Also suitable for T10XX devices.
devices. Size (height x width x depth): 150 x 211 x 45 mm
Size (height x width x depth): 176 x 235 x 45 mm Included:
Included: - Mounting plates (vertically folding devices for easy
- Mounting plates (vertically folding devices for easy installation).
installation). - Multi-box linking accessories.
- Multi-box linking accessories. - Screws.
- Screws. - Plugs.
- Plugs. - Isolating metallic plate to devide power from VDI.
- Side cover for trunking system incoming. - Claws for drywall.
- Isolating metallic plate to devide power from VDI. Suitable for frames code: T1174.
Suitable for frames code: T1173.

White T1193 BL 2CLA119300T1001 1
Silver T1193 PL 2CLA119300T1301 1 T1093 2CLA109300T1001 1

Surface mounting box - 4 columns Flush mounting box - 4 columns
Zenit workstation box for surface mounted installations. Zenit workstation box for flush mounted installations.
4-columns - 2+2+2+2+2+2+2+2 modules. 4-columns - 2+2+2+2+2+2+2+2 modules.
For 1 or 2 module devices. Also suitable for T10XX For 1 or 2 module devices. Also suitable for T10XX
devices. devices. 11
Size (height x width x depth): 176 x 295 x 45 mm Size (height x width x depth): 150 x 271 x 45 mm
Included: Included:
- Mounting plates (vertically folding devices for easy - Mounting plates (vertically folding devices for easy
installation). installation).
- Multi-box linking accessories. - multi-box linking accessories.
- Screws. - Screws.
- Plugs. - Plugs.
- Side cover for trunking system incoming. - Isolating metallic plate to devide power from VDI.
- Isolating metallic plate to devide power from VDI. - Claws for drywall.
Suitable for frames code: T1174. Suitable for frames code: T1174.

White T1194 BL 2CLA119400T1001 1
Silver T1194 PL 2CLA119400T1301 1 T1094 2CLA109400T1001 1

Surface mounting box - 5 columns
Zenit workstation box for surface mounted installations.
5-columns - 2+2+2+2+2+2+2+2+2+2 modules.
For 1 or 2 module devices. Also suitable for T10XX
devices.
Size (height x width x depth): 176 x 355 x 45 mm
Included:
- Mounting plates (vertically folding devices for easy
installation).
- Multi-box linking accessories.
- Screws.
- Plugs.
- Side cover for trunking system incoming.
- Isolating metallic plate to devide power from VDI.
Suitable for frames code: T1175.

White T1195 BL 2CLA119500T1001 1
Silver T1195 PL 2CLA119500T1301 1
