Page 1740 - Din prodcuts 2020

11/634 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
ocean®
IP 44

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
1
Rocker switch ) ) ) Rocker switch ) )
3
1
2
1gang 2way 1gang 2way
Rated voltage: 250 V~ With labelling field.
Rated current: 10 AX Labelling field 57.8 x 9.8 mm
Protection class (Device): IP 44 Rated voltage: 250 V~
Rated current: 10 AX
Protection class (Device): IP 44
grey / 2601/6 W-53-500 2CKA001085A1637 10/100
blue-green grey / 2601/6 WN-53-500 2CKA001085A1635 10/100
alpine white 2601/6 W-54-500 2CKA001085A1632 10/100 blue-green
1) Label holder 1763-53. alpine white 2601/6 WN-54 2CKA001085A1624 10/100
2) Label holder illuminable with illumination insert 2152 NLI-53. 1) Label holder illuminable with illumination insert 2152 NLI-53.
3) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com. 2) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
Rocker switch ) ) ) Rocker switch ) ) ) ) )
3
1
2
3
5
2
1
4
2gang 1way 1gang 2way
Rated voltage: 250 V~ With red neon lens.
Rated current: 10 AX With neon lamp.
Protection class (Device): IP 44 With N terminal.
Rated voltage: 250 V~
grey / 2601/5 W-53-500 2CKA001085A1633 10/100 Rated current: 10 AX
blue-green Protection class (Device): IP 44
alpine white 2601/5 W-54 2CKA001085A1621 10 grey / 2601/6 SKW-53-500 2CKA001085A1636 10/100
blue-green
1) Label holder 1763-53.
2) Label holder illuminable with illumination insert 2152 NLI-53. alpine white 2601/6 SKW-54 2CKA001085A1622 10
3) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
11
1) Label holder 1763-53.
2) Label holder illuminable with illumination insert 2152 NLI-53.
Rocker switch ) ) ) 3) Neon lamp 8346-1 included.
2
3
1
4) Switch illuminable by inserting the lamp 8332-1, 8335-1, 8346-1, 8333-1 and 8358.
1gang 5) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
Rated voltage: 250 V~
Rated current: 10 AX
Protection class (Device): IP 44 Rocker switch with marking "Heizung" ) ) ) ) )
3
1
2
5
4
1gang 2way
With red neon lens.
grey / 2601/7 W-53 2CKA001085A1604 10/100
blue-green With neon lamp.
With labelling field.
alpine white 2601/7 W-54 2CKA001085A1620 10 Labelling field 57.8 x 9.8 mm
1) Label holder 1763-53. With N terminal.
2) Label holder illuminable with illumination insert 2152 NLI-53. Rated voltage: 250 V~
3) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
Rated current: 10 AX
Protection class (Device): IP 44
Rocker switch ) ) ) grey / 2601/6 SKWNH-53 2CKA001085A1609 10/100
3
2
1
breaking circuit, 2-pole blue-green
Rated voltage: 250 V~ alpine white 2601/6 SKWNH-54 2CKA001085A1631 10
Rated current: 10 AX
Protection class (Device): IP 44 1) Label holder illuminable with illumination insert 2152 NLI-53.
2) Switch illuminable by inserting the lamp 8332-1, 8335-1, 8346-1, 8333-1 and 8358.
3) Neon lamp 8346-1 included.
grey / 2601/2 W-53 2CKA001085A1605 10/100 4) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
blue-green 5) Neutral labelling field enclosed.
alpine white 2601/2 W-54 2CKA001085A1627 10
3
1
2
1) Label holder 1763-53. Rocker switch with marking "Heizung" ) ) ) ) )
5
4
2) Label holder illuminable with illumination insert 2152 NLI-53. breaking circuit, 2-pole
3) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
With red neon lens.
With neon lamp.
With labelling field.
Rocker switch ) ) ) )
1
2
3
4
1gang 2way Labelling field 57.8 x 9.8 mm
With neutral (transparent) lens. Rated voltage: 250 V~
With illumination. Rated current: 16 AX
Rated voltage: 250 V~ Protection class (Device): IP 44
Rated current: 10 AX grey / 2601/2 SKWNH-53 2CKA001085A1610 10
Protection class (Device): IP 44 blue-green
grey / 2601/6 WGL-53 2CKA001085A1613 10 alpine white 2601/2 SKWNH-54 2CKA001085A1623 10
blue-green 1) Label holder illuminable with illumination insert 2152 NLI-53.
alpine white 2601/6 WGL-54 2CKA001085A1626 10 2) Switch illuminable by inserting the lamp 8332-1, 8335-1, 8346-1, 8333-1 and 8358.
3) Neon lamp 8346-1 included.
1) Label holder 1763-53.
4) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
2) Label holder illuminable with illumination insert 2152 NLI-53.
5) "Heizung" inscription label also included.
3) Switch illuminable by inserting the lamp 8332-1, 8335-1, 8346-1, 8333-1 and 8358.
4) Neon lamp 8346-1 included.
