ABB i-bus® KNX
Multifunction Room Automation –
Room Controller Function Modules

Binary Input Modules, 4-fold
Each of the modules provides 4 inputs. There are 3 module types available for the connec-
tion of 115/230 V, 12/24 V (AC or DC) or floating contacts to cover all demands.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
BE/M 4.230.1 Type code Order code kg pc.
230 V – BE/M 4.230.1 2CDG110005R0011 0.13 1
12/24 V – BE/M 4.24.1 2CDG110006R0011 0.13 1
Contact Scanning – BE/M 4.12.1 2CDG110007R0011 0.13 1

Switch Actuator Module, 2-fold, 6 A
For switching loads up to 16 A at a maximum continuous current of 6 A.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code kg pc.
SA/M 2.6.1 – SA/M 2.6.1 2CDG110002R0011 0.17 1

Switch Actuator Module, 2-fold, 16 A
For switching two loads up to 16 A. The switched voltage is independent of the basic device
and is connected directly to the module.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
SA/M 2.16.1 Type code Order code kg pc.
– SA/M 2.16.1 2CDG110100R0011 0.16 1
