14/100 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
ABB i-bus® KNX
Heating, Ventilation and Air Conditioning

Application Controller, MDRC
The AC/S Application Controller has predefined Automation Modules for a holistic HVAC Au-
tomation Solution from Central HVAC to Room Automation. For example Schedule, Set Point
Calculation, Heat Curve Calculation, Data Logging and Device Monitoring. Furthermore own
Automation Modules can be created by a graphical Logic Editor. By a web based User Inter-
face the whole system can be monitored and managed. The AC/S 1.2.1 has additional a built
in bidirectional KNX-BACnet/IP Gateway (Server) for data exchange with superordinate
AC/S 1.1.1
Building Management Systems.
The Engineering is done completely by the ETS Version 5.6.5 or higher. An additional external
Software is not required. The device has a KNX TP port and requires for operation an auxil-
iary power supply, either via 24 V AC/DC or via PoE.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code kg pc.
Basic 4 AC/S 1.1.1 2CDG110205R0011 0.19 1
BACnet 4 AC/S 1.2.1 2CDG110206R0011 0.19 1

14
