ABB i-bus® KNX
Automation, Logic and Time Control

Radio Time Switch, 8 Channels, MDR
The Radio Time Switch sends current time and date on the bus. The time can be optionally
received via a DCF or GPS antenna. Furthermore the device can be used to easily adjust the
time programs.
The device provides 8 channels. Every channel supplies an independent daily, time and/or
yearly program. Additionally, special programs (e.g. for vacation or public holiday days) are
FW/S 8.2.1 possible.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code kg pc.
3 FW/S 8.2.1 2CDG120039R0011 0.33 1

DCF Antenna for Radio Time Switch, SM
For the connection to the Radio Tme Switch FW/S 8.2.1. The time signal from the DCF 77
transmitter can be received within a radius of approx. 1000 km around Frankfurt.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
FAD/A 1.1
– FAD/A 1.1 2CDG120040R0011 0.17 1

GPS Antenna for Radio Time Switch, SM
For the connection to the Radio Time Switch FW/S 8.2.1. The device receives time and date
via GPS signal which is available worldwide.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
FAG/A 1.1 Type code Order code kg pc. 14
– FAG/A 1.1 2CDG120041R0011 0.21 1

Programming Set OBELISK top2 for Radio Time Switch
The programming set contains a CD ROM with the Obelisk top2 for the creation of switching
programs for the Radio Time Switch FW/S 8.2.1, a memory card PK/E 2.1 for transferring
switching programs to the Radio Time Switch and a USB programming adapter for the mem-
ory card.

PS/E 2.1
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
– PS/E 2.1 2CDG120042R0011 0.20 1
