ABB i-bus® KNX
User Operation – Design Ranges – ABB i-bus® KNX sensor PEONIA®

ABB i-bus®KNX sensor PEONIA® control element 5/10-fold NEW
with Room Temperature Controller, FM
With integrated bus coupling unit and temperature sensor. Proximity sensor, device locking
and energy saving function.
Switch contact left/right. Replaceable rocker without icon.
Push button function: switching/dimming/blind/value sending/step-type switch/
lightscene/ fan function.
With base-load operation. The controller is a constant room temperature controller for
ventilator convectors (fan-coil).
In 2 and 4 pipe system and conventional heating and cooling systems. The fan stage can be
switched manually or automatic mode.
Delicated capactive touch RTC control button with vibration feedback, Single/Master/Slave
PEBR/U5.0.1-201 configuration.
LCD display: Setpoint/actual temperature, Fan speed, Operating state, Operating mode.
Configurable: time, PM2.5, CO 2 , Humidity, VOC, temperature, Dynamic animation for
dimming, blind, scene.
Individual programmable LED per rocker. Top and bottom ambient LED strip.
LED colour: red/green/yellow/blue/red-orange/violet/white.
Temperature range (device): -5°C to 45°C. Dimensions (L x W): 141 mm x 86 mm.
Only available on the Chinese market.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
Gloss White – PEBR/U5.0.1-002 2TAZ730510R0020 0.284 1
Matt White – PEBR/U5.0.1-001 2TAZ730510R0010 0.284 1
Matt Black – PEBR/U5.0.1-201 2TAZ730510R2010 0.284 1
Matt Silver – PEBR/U5.0.1-131 2TAZ730510R1310 0.284 1
Matt Platinum – PEBR/U5.0.1-151 2TAZ730510R1510 0.284 1
Matt Champagne Gold – PEBR/U5.0.1-411 2TAZ730510R4110 0.284 1
14
Replaceable rocker without icon for ABB i-bus®KNX sensor PEONIA® NEW
control element, PEB/U2.0.1-xxx
Dimensions (L x W): 43 mm x 78 mm.
Only available on the Chinese market.
PESX/U2.10.1-201
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
Gloss White – PESX/U2.10.1-002 2TAZ730000R0020 0.087 1
Matt White – PESX/U2.10.1-001 2TAZ730000R0010 0.087 1
Matt Black – PESX/U2.10.1-201 2TAZ730000R2010 0.087 1
Matt Silver – PESX/U2.10.1-131 2TAZ730000R1310 0.087 1
Matt Platinum – PESX/U2.10.1-151 2TAZ730000R1510 0.087 1
Matt Champagne Gold – PESX/U2.10.1-411 2TAZ730000R4110 0.087 1
