ABB i-bus® KNX
User Operation – Design Ranges – ABB i-bus® KNX sensor PEONIA®

ABB i-bus®KNX sensor PEONIA® control element 5/10-fold, FM NEW
With integrated bus coupling unit and temperature sensor.
Proximity sensor, device locking and energy saving function.
Switch contact left/right. Replaceable rocker without icon.
Push button function: switching/dimming/blind/value sending/step-type switch/lightscene.
Individual programmable LED per rocker. Top and bottom ambient LED strip.
LED colour: red/green/yellow/blue/red-orange/violet/white.
Dimensions (L x W): 144 mm x 86 mm.
Only available on the Chinese market.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
PEB/U5.0.1-201 Type code Order code kg pc.
Gloss White – PEB/U5.0.1-002 2TAZ730500R0020 0.275 1
Matt White – PEB/U5.0.1-001 2TAZ730500R0010 0.275 1
Matt Black – PEB/U5.0.1-201 2TAZ730500R2010 0.275 1
Matt Silver – PEB/U5.0.1-131 2TAZ730500R1310 0.275 1
Matt Platinum – PEB/U5.0.1-151 2TAZ730500R1510 0.275 1
Matt Champagne Gold – PEB/U5.0.1-411 2TAZ730500R4110 0.275 1

ABB i-bus®KNX sensor PEONIA® control element 2/4-fold NEW
with Room Temperature Controller, FM
With integrated bus coupling unit and temperature sensor. Proximity sensor, device locking
and energy saving function Switch contact left/right. Replaceable rocker without icon.
Push button function: switching/dimming/blind/value sending/step-type switch/
lightscene/ fan function.
With base-load operation.
The controller is a constant room temperature controller for ventilator convectors (fan-coil)
PEBR/U2.0.1-201
in 2 and 4 pipe system and conventional heating and cooling systems.
The fan stage can be switched manually or automatic mode.
Delicated capactive touch RTC control button with vibration feedback, Single/Master/Slave 14
configuration.
LCD display: Setpoint/actual temperature, Fan speed, Operating state, Operating mode.
Configurable: time, PM2.5, CO 2 , Humidity, VOC, temperature, Dynamic animation for
dimming, blind, scene.
Individual programmable LED per rocker. Top and bottom ambient LED strip.
LED colour: red/green/yellow/blue/red-orange/violet/white.
Temperature range (device): -5°C to 45°C. Dimensions (L x W): 86 mm x 86 mm.
Only available on the Chinese market.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
Gloss White – PEBR/U2.0.1-002 2TAZ730210R0020 0.212 1
Matt White – PEBR/U2.0.1-001 2TAZ730210R0010 0.212 1
Matt Black – PEBR/U2.0.1-201 2TAZ730210R2010 0.212 1
Matt Silver – PEBR/U2.0.1-131 2TAZ730210R1310 0.212 1
Matt Platinum – PEBR/U2.0.1-151 2TAZ730210R1510 0.212 1
Matt Champagne Gold – PEBR/U2.0.1-411 2TAZ730210R4110 0.212 1
