14/206 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
ABB i-bus® KNX
User Operation – Design Ranges –
Planning aid for Busch-priOn®

End strips without function

studio white, glass black,
Article-No. 6348-24G-101-500 Article-No. 6348-825-101-500

white glass, stainless steel,
Article-No. 6348-811-101-500 Article-No. 6348-860-101-500

Support frame,
bus coupler

1gang,
Article-No.
Bus coupler Busch-priOn®,
Article-No. 6120/12-101 6346/10-101-500

Note:
This power adaptor
can supply up to 15
power bus couplers
with current.

Power adaptor Bus coupler Busch-priOn®,
REG, Article-No. 6120/13-500
Article-No.
CP-D 24/2.5
2gang,
Without end strip incl. temperature reading Article-No.
6346/11-101-500
FM actuators
3gang,
Article-No.
14
6346/12-101-500
Switch actuator, Universal dimming Serial/blind actuator,
1gang, FM actuator, 1gang, 2/1gang, FM
2.300 w/VA, FM 10–450 w/VA, 2.300 w/VA,
Article-No. Article-No. Article-No.
6354 U-500 6355 U-500 6356 U-500

End strip End strips without
function

studio white,
Article-No. 6349-24G-101-500

white glass,
Commissioning adaptor, Article-No. 6349-811-101-500
Article-No. 6149/21-500

glass black,
Article-No. 6349-825-101-500

stainless steel,
Article-No. 6349-860-101-500
