ABB i-bus® KNX
User Operation – Design Ranges – Busch-priOn®

Universal Dim Actuator, 1-fold, FM, Busch-priOn®
For dimming and switching of incadescent lamps, 230 V halogen lamps and low-voltage hal-
ogen lamps with conventional or electronic transformers. 2-wire connection (neutral con-
ductor not required). Do not operate conventional transformers and electronic transformers
together on the universal dimmer switch insert. Can be used only in connection with support
frame 2gang (6346/11-101-500) and 3gang (6346/12-101-500). Not combinable with the bot-
tom end strip with temperature sensor (6352-xxx-101-500).
6355 U-500
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit

Type code Order code kg pc.
– 6355 U-500 2CKA006310A0098 0.103 1

Base Frame, 1-fold, Busch-priOn®
For Busch-priOn® for seating and contact connection of rotary control elements, operating
element 1-fold and 3-fold as well as the top/bottom finishing strip. For contacting with the
Bus Coupler priOn or Power Bus Coupler priOn.

6346/10-101-500
Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
– 6346/10-101-500 2CKA006310A0135 0.012 1

Base Frame, 2-fold, Busch-priOn®
For Busch-priOn® for seating and contact connection of 8.89 cm (3.5") TFT colour display
with rotary control element, rotary control element 1-fold and 3-fold as well as the top/bot-
tom finishing strip. For contacting with the Power Bus Coupler priOn.

Description Mod. Order details Price Weight Pack 14
width 1 piece 1 piece unit
6346/11-101-500
Type code Order code kg pc.
– 6346/11-101-500 2CKA006310A0137 0.116 1

Base Frame, 3-fold, Busch-priOn®
For Busch-priOn® for seating and contact connection of 8.89 cm (3.5") TFT colour display
with rotary control element, rotary control element 1-fold and 3-fold as well as the top/bot-
tom finishing strip. For contacting with the Power Bus Coupler priOn.

Description Mod. Order details Price Weight Pack
width 1 piece 1 piece unit
Type code Order code kg pc.
– 6346/12-101-500 2CKA006310A0139 0.159 1
6346/12-101-500
