          ABB i-bus® KNX
          User Operation – Design Ranges –
          Push Button Coupling Unit


                                    Rocker 1gang, with “Dimmer” icon
                                    As cover for KNX 2gang push-button coupling unit (6108/06-500).


                                    Description          Mod.  Order details                Price Weight  Pack
                                                         width                             1 piece 1 piece  unit
                                                              Type code     Order code           kg      pc.
                                    Reflex SI
         SRD-1-84
                                    white                –    SRD-1-212     2CKA006220A0190      0.013   1
                                    alpine white         –    SRD-1-214     2CKA006220A0191      0.013   1

                                    future® linear
                                    anthracite           –    SRD-1-81      2CKA006220A0149      0.017   1
                                    ivory                –    SRD-1-82      2CKA006220A0520      0.014   1
                                    aluminium silver     –    SRD-1-83      2CKA006220A0150      0.017   1
                                    studio white         –    SRD-1-84      2CKA006220A0151      0.017   1
                                    studio white matt    –    SRD-1-884     2CKA006220A0605      0.018   1
                                    black, matt          –    SRD-1-885     2CKA006220A0622      0.018   1

                                    solo®
                                    ivory                –    SRD-1-82      2CKA006220A0520      0.014   1
                                    studio white         –    SRD-1-84      2CKA006220A0151      0.017   1
                                    grey metallic        –    SRD-1-803     2CKA006220A0554      0.018   1

                                    Busch-axcent®
                                    studio white         –    SRD-1-84      2CKA006220A0151      0.017   1

                                    pure stainless steel
                                    stainless steel      –    SRD-1-866     2CKA006220A0537      0.018   1

                                    carat®
                                    anthracite           –    SRD-1-81      2CKA006220A0149      0.017   1             14
                                    ivory                –    SRD-1-82      2CKA006220A0520      0.014   1
                                    studio white         –    SRD-1-84      2CKA006220A0151      0.017   1

                                    Dynasty®
                                    anthracite           –    SRD-1-81      2CKA006220A0149      0.017   1
                                    ivory                –    SRD-1-82      2CKA006220A0520      0.014   1
                                    antique brass        –    SRD-1-840     2CKA006220A0375      0.018   1


                                    Push-button coupling 4gang with integrated bus coupler
                                    Support of KNX functions through innovative colour concept yellow = lighting, blue = blind,
                                    orange = RTC, magenta = scene and white = neutral/no function assigned) or standard illu-
                                    mination red/green. With middle position. The bus can be connected via enclosed terminal
                                    block.

                                    Description          Mod.  Order details                Price Weight  Pack
          6108/07-500                                    width                             1 piece 1 piece  unit

                                                              Type code     Order code           kg      pc.
                                                         –    6108/07-500   2CKA006133A0223      0.075   1
