          ABB i-bus® KNX
          User Operation – Design Ranges




                                    Control Element, 6gang with Universal Input, 5gang
                                    Control element with a maximum of 6 control functions and an RTC extension unit (slave).
                                    Primary function for calling up the main function. Status bar for indication/display of oper-
                                    ating or RTC functions. Operation is carried out via cover plate 6108/61-xxx. With actual
                                    value temperature display. With display of set-value temperature. With universal input with:
                                    - max. of 5 binary inputs - 4 binary inputs and 1 analogue input for activating sensors with
                                    external power supply 1-10 V/0-10 V - 2 binary inputs and 1 analogue input for activating sen-
          6108/60-500               sors with external power supply 1-10 V/0-10 V and an external temperature sensor PT1000 /
                                    T6226. The bus can be connected via enclosed terminal block.

                                    Description          Mod.  Order details                Price Weight  Pack
                                                         width                             1 piece 1 piece  unit
                                                              Type code     Order code           kg      pc.
                                                         –    6108/60-500   2CKA006115A0454              1


                                    Cover Plate for KNX Control Element, 7gang
                                    As cover for control element, 7gang (6108/60).

                                    Description          Mod.  Order details                Price Weight  Pack
                                                         width                             1 piece 1 piece  unit

                                                              Type code     Order code           kg      pc.
                                    white                –    6108/61-212-500  2CKA006115A0474   0.012   1
          6108/61-212-500
                                    alpine white         –    6108/61-214-500  2CKA006115A0475   0.012   1
                                    platinum             –    6108/61-20-500  2CKA006115A0476    0.016   1
                                    bronze               –    6108/61-21-500  2CKA006115A0477    0.016   1
                                    ivory/white          –    6108/61-22G-500  2CKA006115A0478   0.016   1
                                    studio white matt  1)  –  6108/61-24-500  2CKA006115A0479    0.016   1
                                    studio white         –    6108/61-24G-500  2CKA006115A0480   0.016   1
                                    palladium            –    6108/61-260-500  2CKA006115A0481   0.016   1
                                    titanium             –    6108/61-266-500  2CKA006115A0482   0.016   1
  14
                                    anthracite           –    6108/61-81-500  2CKA006115A0483    0.018   1
                                    ivory white          –    6108/61-82-500  2CKA006115A0484    0.018   1
                                    aluminium silver     –    6108/61-83-500  2CKA006115A0485    0.018   1
                                    studio white         –    6108/61-84-500  2CKA006115A0486    0.018   1
                                    studio white matt    –    6108/61-884-500  2CKA006115A0487   0.018   1
                                    black matt           –    6108/61-885-500  2CKA006115A0488   0.018   1
                                    grey metallic        –    6108/61-803-500  2CKA006115A0489   0.02    1
                                    stainless steel      –    6108/61-866-500  2CKA006115A0492   0.018   1
                                    1)  to be discontinued


                                    Cover Plate, Control Element, 7gang
                                    As cover for control element, 7gang (6108/60).


                                    Description          Mod.  Order details                Price Weight  Pack
                                                         width                             1 piece 1 piece  unit
                                                              Type code     Order code           kg      pc.
                                    white                –    6108/61-914   2CKA006155A0115              1
          6108/61-914
                                    stainless steel      –    6108/61-840-500  2CKA006155A0121   0.018   1
