          ABB i-bus® KNX
          User Operation – Design Ranges –
          Push Button Coupling Unit


                                    Push-button coupler 2gang with integrated bus coupler
                                    For contacting conventional 1gang rocker switches. With middle position. For inserting in
                                    the ocean surface-mounted housing. Enclosed mounting plate for the following ranges:
                                    Busch-Duro 2000 SI/SI Linear, Reflex SI/SI Linear, future® linear, alpha, solo®, Busch-axcent®,
                                    carat® and pure stainless steel. The bus can be connected via enclosed terminal block.

          6108/06-AP-500            Description          Mod.  Order details                Price Weight  Pack
                                                         width                             1 piece 1 piece  unit
                                                              Type code     Order code           kg      pc.
                                    1/2-fold             –    6108/06-AP-500  2CKA006133A0225    0.1     1
                                    2/4-fold             –    6108/07-AP-500  2CKA006133A0227    0.091   1


                                    Push-button coupler 2gang with integrated bus coupler
                                    For contacting 1gang rocker 6230-10-xxx, 6231-10-xxx, 6232-10-xxx, 6233-10-xxx und 6234-
                                    10-xxx. With integrated temperature sensor. Support of KNX functions through innovative
                                    colour concept (yellow=lighting, blue=blind, orange=RTC, magenta=scene and white=neu-
                                    tral/no function assigned) or standard illumination red/green. With middle position. The bus
                                    connection is provided via the enclosed bus terminal.
          6108/06-500
                                    Description          Mod.  Order details                Price Weight  Pack
                                                         width                             1 piece 1 piece  unit
                                                              Type code     Order code           kg      pc.
                                                         –    6108/06-500   2CKA006133A0221      0.06    1
