IP21/54 ventilation kits
• Composed of plastic grills and filter to ensure switchboard ventilation.
• Degree of protection without filter: IP21.
• Degree of protection with filter: IP54.
• Preassembled seal.

Description Dimensions Code Unit/Pack
(mm)
Grid + air flow kit 105x105 EN0105K 1/1
Grid + air flow kit (not suitable for size. 1) 150x150 EN0150K 1/1
Grid + air flow kit (not suitable for size. 1) 204x204 EN0204K 1/1
Note: screws not included; use 4 self lock screws 2,9x13 or ask for order code 1SL0384A00.
Ventilation kit

Base covers
For aesthetic as well as functional purposes, in particular for pedestal installations.

Size of the switchboard Code Unit/Pack
1 1SL0385A00 1/4
2 1SL0386A00 1/4
3 1SL0387A00 1/2
4 1SL0388A00 1/2
5 1SL0389A00 1/2
6 1SL0390A00 1/2

Base cover

Coupling kits
It follows the aesthetic outline of the boxes.

Description Code Unit/Pack
Vertical coupling kit for sizes 2-3 switchboards 1SL0413A00 1/2
Vertical coupling kit for sizes 4 switchboards 1SL0414A00 1/2
Vertical coupling kit for sizes 5 switchboards 1SL0415A00 1/2
Vertical coupling kit for sizes 6 switchboards 1SL0416A00 1/2
Coupling kit
