ABB | SACE Emax 2
Supporting software and Different softwares and documents are available; the majority are free of charge and are designed to facilitate,
documents optimize and extend the functions and configurations of Ekip Touch in your installation:
NOTE: some of the documents mentioned in the next table refer to SACE Emax 2, but can
also be used with SACE Tmax XT7

Ekip Connect 3
ABB software to interface with Ekip Touch and other low voltage devices (link)

EPiC
ABB APP to interface with Ekip Touch using a smartphone / tablet via Bluetooth (link)

Ekip View
ABB software which supervises the communication network, analyzes the trend of the electricity values and
monitors the plant conditions (1SDH001276R0001)
NOTE: the link launches the software package download, which requires about 1.3 Gb of space.

e-Design
ABB software suite (link) which includes the following tools:
• DOC, to design the single-line diagrams of low and medium voltage electrical installations, choose the
operating and protection devices and check and coordinate the protections
• CAT, for technical / commercial cost estimating of ABB products
• Curves, for drawing, calibrating and printing the trip curves of the protection devices
• OTC, for assessing the thermal behavior of the switchgear and sizing its fans and air conditioners
• UniSec, for configuring medium voltage switchgear

Front CAD
Software comprising libraries of block graphics for ABB panel-making products to be used with the latest
versions of AutoCAD, AutoCAD LT, IntelliCAD (link)
NOTE: the link launches the software package download, which requires about 190 Mb of
space.

Ekip Link
Introduction to the Ekip Link switchgear monitoring system (1SDC200031l0202)

Network Analyzer
Introduction to the Network Analyzer measuring and analysis system (1SDC200037l0202)

Adaptive protectionsProtezioni adattive
White paper on adaptive protections (1SDC007116G0201)

Generator protections
White Paper on generator protections (1SDC007409G0202)

Power Controller
White Paper on the Power Controller function (1SDC007410G0202)

Continued on the next page

9 | © 2019 ABB | 1SDH001316R1002 - ECN000086501 - Rev. A Overview of Ekip Touch | 3 - Accessories and software
