3/4              SACE TMAX XT LOW VOLTAGE MOLDED CASE CIRCUIT-BREAKERS



          —

          Reading information


          Information on how to read the diagrams

















                           State of operation shown                    K       = Motor starting contactor
                           The diagrams are shown in the following conditions:  K51    = Ekip type electronic relay for
                           •  fixed version circuit-breaker, open;               overcurrent protection
                           •  withdrawable or plug-in version circuit-breaker,   K51/CI   = Motor starting contactor operator
                            open and connected;                                  module
                           •  contactor for starting the motor open;   K51/COM  = Communication module
                           •  circuits de-energised;                   K51/MEAS= Measurement module
                           •  trip units not tripped;                  K51/SIGN = Signaling module
                           •  motor operator with springs charged.     K51/SUPPLY = Auxiliary supply module
                                                                                    (110-24OVAC/DC and 24-48VDC)
                           Key XT1...XT4                               K51/SYNC = Synchronizing module
                           *       = See note indicated by the letter  K51/TEMP = Temperature monitoring module
                           A12     = Ekip Com type interface unit      K87     = Residual current relay
                           A13     = Ekip Signaling 10K type signaling unit  M    = Motor with energizing in series for
                           A14     = MOE-E type stored energy motor              circuit-breaker opening and closing
                                     operator actuating unit                     (Fig. 21)
                           A15     = Ekip Multimeter type measurement    M     = Motor for opening circuit-breaker and
                                     unit                                        loading the closing springs (Fig. 22-
                           A16     = Ekip Micro Module l/O type interface        54-55-56-57)
                                     unit                              M1      = Three-phase asynchronous motor
                           A17     = MOE type stored energy motor      0 11...32   = Programmable signaling contacts
                                     operator actuating unit           OCI     = Contact for motor starting contactor
                           BUS1    = Serial interface with external bus          operating mechanism
                           BUS2    = Redundant serial interface with external    0 SC    = Synchronism monitoring contact
                                     bus                               Q       = Main circuit-breaker
                           LINK BUS = Interface with external Link bus  Q/O...7   = Auxiliary contacts of the circuit-
                                     D 2 Electronic time-delay device for        breaker open/closed
                                     undervoltage release coil YU, outside    R-R1    = Resistor
                                     circuit-breaker (only for voltage up to    R2    = Pt100 temperature sensor of motor
                                     250 V)                            81      = Contact controlled by the motor
                           H2      = Signaling lamp for stored energy motor         operator cam
                                     operator blocked                  82      = Contact controlled by the key lock of
                           I 11...32   = Programmable digital inputs             the direct action motor operator
                           | 41...43 51...53 = Analog inputs from temperature    83/1-2    = Contacts operated by Auto/Manual
                                               sensor                            selector switch and by key lock of the
                           | 44-54   = Analog inputs from 4-20mA sensor          stored energy motor operator
                           | Pt1OO   = Analog input from PtiOO temperature    S4    = Contact operated by direct action
                                     sensor of motor                             motor operator cam
                           I reset    = Digital input for resetting tripped mo   S4/1-2   = Early auxiliary contacts operated by
                                     tor starting contactor operating unit       circuit-breaker mounted crank handle
                           J...    = Connectors for auxiliary circuits of    851    = Contact for signaling circuit-breaker
                                     withdrawable circuit-breaker.               open due to tripped thermomagnetic
                                     Withdrawal of connectors occurs at          overcurrent protection release or
                                     the same time as that of circuit-           electronic relay
                                     breaker
