MOULDED CASE CIRCUIT BREAKERS
TMAX XT2

EKIP LS/I ELECTRONIC TRIP UNIT
Current L - I 1 S/I - I /I 3 Reference
2
Rating In (A) 0.4 to 1 x In (A) 1 to 10 x In (A) No. Part No.
3 Pole
25 10-25 25-250 XT2N3LS/I025 1SDA067055R1
63 25.2-63 63-630 XT2N3LS/I063 1SDA067056R1
100 40-100 100-1000 XT2N3LS/I100 1SDA067057R1
36kA 4 Pole 160 64-160 160-1600 XT2N3LS/I160 1SDA067058R1 MCCB

25 10-25 25-250 XT2N4LS/I025 1SDA067091R1
63 25.2-63 63-630 XT2N4LS/I063 1SDA067092R1
100 40-100 100-1000 XT2N4LS/I100 1SDA067093R1
160 64-160 160-1600 XT2N4LS/I160 1SDA067095R1

3 Pole
25 10-25 25-250 XT2H3LS/I025 1SDA067858R1
63 25.2-63 63-630 XT2H3LS/I063 1SDA067859R1
1SDA067054R1 100 40-100 100-1000 XT2H3LS/I100 1SDA067860R1
160 64-160 160-1600 XT2H3LS/I160 1SDA067861R1
70kA 4 Pole 25 10-25 25-250 XT2H4LS/I025 1SDA067891R1

63 25.2-63 63-630 XT2H4LS/I063 1SDA067892R1
100 40-100 100-1000 XT2H4LS/I100 1SDA067893R1
160 64-160 160-1600 XT2H4LS/I160 1SDA067895R1

ACCESSORIES

Part No. Part No.
Description Direct Extended
Rotary Handles 1SDA069053R1 1SDA069055R1

Part No. Part No.
Description 3P 4P
Terminal Cover - Low Size 1SDA066657R1 1SDA066659R1
Direct Handle Extended Handle
Terminal Cover - High Size 1SDA066666R1 1SDA066667R1
Part No. Part No.
Description ½ Kit for 3P ½ Kit for 4P
Front terminal 1SDA066853R1 1SDA066854R1
Extended front terminals 1SDA066869R1 1SDA066870R1
Terminal Cover Front Terminal
Extended spread front terminals 1SDA066893R1 1SDA066894R1
Rear adjustable terminals 1SDA066941R1 1SDA066942R1
- Please refer from page no. 56 for other accessories.
