W66 INDUSTRIAL SWITCHGEAR

SINGLE PHASE EXTENSION SOCKETS - 250V

Current
Features: Rating (A) No Pins Type Max Cable Gland Part No.
Style
mm²
- IP66 Rating.
- Orange ring, clear bodies. 10 W66ES310
- Stainless steel fixings. 15 3 Flat 2.5 1 W66ES315
20 W66ES320F
20 6 2 W66ES320
32 3 Round 16 3 W66ES332

W66ES310

W66ES332

THREE PHASE EXTENSION SOCKETS - 500V
Features: Current Pins Max Cable Gland
- IP66 Rating. Rating (A) No Type mm² Style Part No. WEATHERPROOF
- Orange ring, clear bodies. SWITCHING
- Stainless steel fixings. 10 6 2 W66ES410
- Silicone cover seal. 20 W66ES420
32 4 Round W66ES432
40 16 3 W66ES440
50 W66ES450
10 6 2 W66ES510
20 W66ES520
32 5 Round W66ES532
40 16 3 W66ES540
W66ES510 50 W66ES550

CABLE GLAND STYLE

1 2 3
Type M20 M25 37mm
small body small body compression
Cable min dia 6mm 8mm 7mm
Cable max dia 10mm 17mm 16mm
1 2
Alternative AG20BK AG25BK PG29
Dia range 10 - 14mm 13 - 18mm 16 - 25mm

3
