W66 INDUSTRIAL SWITCHGEAR

SINGLE PHASE 3-POSITION CHANGEOVER WITH INLET AND MCB

Voltage
Current
Max
Features: Rating (V) Rating (A) No Pins Type Cable mm² Part No.
- IP66 Rating.
- W66B4 base 2 x M32, 2 x M25 entries. 250 10 3 Flat 6 W66GEN310
- Single phase 250V AC. 15 W66GEN315
- Stainless steel fixings.
- 32A C/O Switch and 10A/15A MCB.
- UV Stabilized.

W66GEN310
WEATHERPROOF
SWITCHING
Features: CHANGEOVER & REVERSING SWITCHES
- IP65 Rating.
- W66B1 base 2 x M25, 1 x M32 entries. Current Rating No. of
- Light grey. (A) Description Modules (M) Part No.
25 Changeover switch 2P 500V AC 1 W66CO225
25 Changeover switch 4P 500V AC 1 W66CO425
40 Changeover switch 2P 500V AC 2 W66CO240
40 Changeover switch 3P 500V AC 2 W66CO340
25 Reversing switch 3P 500V AC 1 W66RS325

W66CO225 W66CO340

Features: BRAIDED INDUSTRIAL EXTENSION LEADS
- IP66 rated Plugs & Sockets.
- Braided shield is earthed. Current Rating Length
- Triple insulated braided flex. (A) (m) Cable Part No.
5 W66EL5M10
10 1.5mm² 3 core screened W66EL10M10
10
20 W66EL20M10
30 2.5mm² 3 core screened W66EL30M10

5 W66EL5M15
10 1.5mm² 3 core screened W66EL10M15
15
20 W66EL20M15
30 2.5mm² 3 core screened W66EL30M15

W66EL5M10
