3/270 ABB MOTOR PROTECTION AND CONTROL

—

NF 8-pole contactor relays
AC / DC operated

NF contactor relays are used for switching auxiliary and control circuits.
These contactor relays are of the block type design with:
03
• 8 poles with a permanently fixed 4-pole auxiliary contact block. Contactor relays have mechanically
linked auxiliary contact elements (side-marked symbol) except for NF33/11 and NF51/11 variants
• overlapping of lagging / leading contacts for NF33/11 and NF51/11 variants
• control circuit: AC or DC operated with electronic coil interface accepting a wide control voltage
1SBC101029V0014 - can manage large control voltage variations
range (e.g. 100...250 V AC and DC)
- only 4 coils to cover control voltages between 24...500 V 50/60 Hz and 20...500 V DC
- reduced panel energy consumption
- very distinct closing and opening
NF44E
• built-in surge suppression
• add-on auxiliary contact blocks for side mounting and a wide range of accessories.
Number of contacts Rated control circuit Type Order code Weight
1st stack 2nd stack voltage Pkg
Uc min. ... Uc max. (1 pce)
V 50/60 Hz V DC kg
8-pole contactor relays
A1 13 23 33 43 51 61 71 81 24...60 20...60 (1) NF44E-11 1SBH137001R1144 0.320
NO NO NO NO NC NC NC NC 48...130 48...130 NF44E-12 1SBH137001R1244 0.320
1SBC101042V0014 A2 NO 14 NO 24 NO 34 NO 44 NC 52 NC 62 NC 72 NC 82 100...250 100...250 NF44E-13 1SBH137001R1344 0.320
NF44E-14
250...500
250...500
1SBH137001R1444
0.360
24...60
13
61
71
81
53
23
33
43
A1
NO
NC
NC
NO
NO
NO
NC
NO
1SBH137001R1253
48...130 20...60 (1) NF53E-11 1SBH137001R1153 0.320
48...130
NF53E-12
0.320
NF33/11 A2 NO 14 NO 24 NO 34 NO 44 NO 54 NC 62 NC 72 NC 82 100...250 100...250 NF53E-13 1SBH137001R1353 0.320
250...500 250...500 NF53E-14 1SBH137001R1453 0.360
A1 13 23 33 43 53 61 71 83 24...60 20...60 (1) NF62E-11 1SBH137001R1162 0.320
NO NO NO NO NO NC NC NO
48...130 48...130 NF62E-12 1SBH137001R1262 0.320
NO NO NO NO NO NC NC NO 100...250 100...250 NF62E-13 1SBH137001R1362 0.320
A2 14 24 34 44 54 62 72 84
250...500 250...500 NF62E-14 1SBH137001R1462 0.360
A1 13 23 33 43 53 61 73 83 24...60 20...60 (1) NF71E-11 1SBH137001R1171 0.320
NO NO NO NO NO NC NO NO
48...130 48...130 NF71E-12 1SBH137001R1271 0.320
NO NO NO NO NO NC NO NO
A2 14 24 34 44 54 62 74 84 100...250 100...250 NF71E-13 1SBH137001R1371 0.320
250...500 250...500 (1) NF71E-14 1SBH137001R1471 0.360
1SBH137001R1180
20...60
NF80E-11
0.320
24...60
83
73
1SBC101043V0014 A2 NO NO 14 NO NO 24 NO 34 NO 44 NO 54 NO 64 NO 74 NO 84 48...130 48...130 NF80E-12 1SBH137001R1280 0.320
13
53
23
A1
63
43
33
NO
NO
100...250
NF80E-13
100...250
0.320
NO
NO
1SBH137001R1380
NO
NO
1SBH137001R1480
0.360
NF80E-14
250...500
250...500
8-pole contactor relays with overlapping of lagging / leading contacts
NF51/11
A1 13 23 33 41 51 61 75 87 24...60 20...60 (1) NF33/11-11 1SBH137001R1139 0.320
NO NO NO NC NC NC NC NO
48...130 48...130 NF33/11-12 1SBH137001R1239 0.320
NO NO NO NC NC NC NC NO 100...250 100...250 NF33/11-13 1SBH137001R1339 0.320
A2 14 24 34 42 52 62 76 88
250...500 250...500 NF33/11-14 1SBH137001R1439 0.320
A1 13 23 33 43 53 61 75 87 24...60 20...60 (1) NF51/11-11 1SBH137001R1159 0.320
NO NO NO NO NO NC NC NO
48...130 48...130 NF51/11-12 1SBH137001R1259 0.320
NO NO NO NO NO NC NC NO 100...250 100...250 NF51/11-13 1SBH137001R1359 0.320
A2 14 24 34 44 54 62 76 88
250...500 250...500 NF51/11-14 1SBH137001R1459 0.320
(1) NF..-11 not suitable for direct control by PLC.
110.5 4.35"
45 1.77" 71 2.80" 10 0.39" 35 1.38"
2 x
5.5 0.22" ø 4.2 0.17" M4 8-32 UNC
6 0.24"
80 3.15" 35 mm EN/IEC 60715 5.5 0.22" 43 1.69" 60 2.36" 70 2.76"
5 0.20"
5 0.20"
NF44E, NF53E, NF62E, NF71E, NF80E, NF33/11, NF51/11
Main dimensions mm, inches
