carat®
Dimmers Movement detectors / comfort switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Control element ) Busch-Universal relay switch insert
1
with neon lamp 3 wire connection (neutral conductor required).
Combinable with Busch-Memory 2gang dimmer 6565 U. For Busch-Watchdog 180 flush-mounted Sensor
Standard 6810-21x-101.
For Busch-Watchdog 180 flush-mounted sensor
Comfort II 6800-xxx-104 and 6800-xxx-104M.
For Busch-Watchdog 180 FP sensor for All Weather 44
anthracite 6545-81 2CKA006599A2906 1/10 6800-3x-102C.
ivory white 6545-82 2CKA006599A2907 1/10 For Busch-Watchdog Presence tech 6813-xxx-101 und
6813/11-xxx.
studio white 6545-84 2CKA006599A2908 1/10
For comfort timer control element 6455-101-500.
1) Replacement neon lamp 3857.
For Busch-Remote control IR control cover 6067-xxx-10x.
For control cover with control lamp 6543-xxx-10x.
Combinable with Busch-Watchdog extension insert
Cover plate
for cooling element 6805 U.
For Busch-Universal master dimmer power module Operation also possible via conventional push buttons
6594 U. (2020 US, 2021/6 UK).
For room temperature controller object range 6108/0x Rated voltage: 230 V~, +10 % / -10 %
and base for blind cover 6930/01. Rated frequency: 50 Hz
Outputs: 1x Normally open contact, potential-bound
anthracite 6541-81 2CKA006599A2882 10 Suitable for: 230 V incandescent lamps, 230 V halogen
lamps, fluorescent lamps and low-voltage halogen
ivory white 6541-82 2CKA006599A2832 10
lamps, that are operated via transformers.
studio white 6541-84 2CKA006599A2835 10 Rated current: 10 AX
Rated power: 2300 W/VA
Temperature range (Device): -25 °C to 55 °C60669-2-1 11

6401 U-102-500 2CKA006401A0049 1/10

Busch-Universal 2gang 1way insert
3 wire connection (neutral conductor required).
For the serial switch operating mode: 2 separate
outputs, 2 separate extension inputs.
For operation mode timer: output 1 (eg lighting),
output 2: ON/Off delay in dependence of output 1 (eg
fan control). For Busch-Watchdog 180 flush-mounted
Sensor Standard 6810-21x-101.
For Busch-Watchdog 180 flush-mounted sensor
Comfort II 6800-xxx-104 and 6800-xxx-104M.
For Busch-Watchdog Presence tech 6813-xxx-101 und
6813/11-xxx. For Busch-Remote control IR control cover
6066-xxx-10x and 6067-xxx-10x.
For control cover 6430-xxx-10x and 6543-xxx-10x.
Combinable with Busch-Watchdog extension insert
6805 U. Operation also possible via conventional push
buttons (2020 US, 2021/6 UK).
Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz
Outputs: 2x Normally open contact, potential-bound
Suitable for: 230 V incandescent lamps, 230 V halogen
lamps, fluorescent lamps and low-voltage halogen
lamps, that are operated via transformers.
Rated current: 10 AX
Rated power: 2300 W/VA
Temperature range (Device): 0 °C to 35 °CBritish
Standard EN 60669-2-1

6402 U-500 2CKA006401A0051 1/10
Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB.
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
neon indicator: neon lamp 3855, one neon lamp is supplied together with
control cover plates 6540-2x.
