Page 1127 - Din prodcuts 2020

11/21

—
carat®
Blind control / timers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Blind switch insert ) ) DIN profile-semi cylindrical lock
2
1
With rotary knob/push button. Acc. to German Standard DIN 18252.
Rated voltage: 250 V~ Total length 40 mm
Rated current: 10 A for blind switches and push switches
Protection class (Device): IP 20 For inserts 2712/2713/2722/2723/2733 USL-101 and
IEC60669-1, British Standard EN 60669-1 2712/2733 SLW-5x.
Protection class (Device): IP 20
DP )
3
2722 U 2CKA001101A0559 10 different lock mechanism, with 3 keys
SP, N, E 0520 PZ-VS 2CKA000470A0013 1/100
2723 U 2CKA001101A0567 10 lock mechanism, with 3 keys
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall 0521 PZ-GS 2CKA000470A0021 1/100
or 3060 wallbox concrete)
2) Blind switches/push switches prevents fast change over between operating 1 2 3
directions. Comfort blind insert ) ) )
3) Also suitable for controlling direct voltage drives. with memory and positioning function
For the manual and automatic control of roller blinds.
The roller blind moves to the position set using the turn
Blind switch/push-switch ) ) ) ) knob.
3
2
1
4
For profile semi-cylindrical lock/switch and push-switch. Executes the individually programmed switching
Delivered without cylindrical lock. commands (UP/DOWN) in a 24-hour rhythm.
Rated voltage: 250 V~ Suitable for roller blind drives with mechanical or
Rated current: 10 AX electronic limit switch shut-off.
Protection class (Device): IP 20 Suitable for operation without neutral conductor. 11
IEC60669-1, British Standard EN 60669-1 Without an extension input.
Power reserve of 45 minutes (maintenance-free as
DP ) capacitor).
5
2712 USL-101 2CKA001101A0872 10 Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz
SP, N, E Outputs: 2x Normally open contact
Rated current: 1.3 A, cos φ 0.5
2713 USL-101 2CKA001101A0880 10
Rated power: 300 VA
1) For installation on British Standard wallboxes please use adapter plate APBS
(6599-0-2813). (Depth of box 60 mm.) Temperature range (Device): 0 °C to 35 °C
2) Blind switches/push switches prevents fast change over between operating
directions. 6419 U 2CKA006410A0390 1/10
3) Use the cylindrical lock according to the enclosed drawing. 1) Pertinent cover plates 6436-xx.
4) See semi-cylindrical lock. 2) N-conductor connection may be required for operation with blind and roller
5) Also suitable for controlling direct voltage drives.
blind drives with electronic limit switch shut-off. If no N-conductor is available,
capacitor set 6498 can be used.
3) Only suitable for single unit control.
Blind switch insert ) ) ) )
1
3
4
2
For profile semi-cylindrical lock/push-button.
Delivered without cylindrical lock. Basic blind insert ) )
2
1
Rated voltage: 250 V~ 2-wire blind insert
Rated current: 10 A Suitable for blind and roller blind drives with mechanical
Protection class (Device): IP 20 or electronic limit switch shut-off.
British Standard EN 60669-1, IEC60669-1 Suitable for operation without neutral conductor.
Without an extension input.
DP ) For control cover 6430-xx-xxx.
5
2722 USL-101 2CKA001101A0898 10 For standard timer control element 6456-101.
Running time: 3 min
SP, N, E Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz
2723 USL-101 2CKA001101A0906 10 Outputs: 2x Normally open contact
1) For installation on British Standard wallboxes please use adapter plate APBS Rated current: 3 A, cos φ 0.5
(6599-0-2813). (Depth of box 60 mm.) Rated power: 690 VA
2) Blind switches/push switches prevents fast change over between operating
directions. Temperature range (Device): 0 °C to 35 °C
3) Use the cylindrical lock according to the enclosed drawing.
4) See semi-cylindrical lock. 6418 U-500 2CKA006410A0376 1/10
5) Also suitable for controlling direct voltage drives.
Mounting 35 mm deep flush 1gang
boxes: or Dual Box 3070-2/35 BSDB.
2gang product 2gang combination with adapter plate
combinations: APBS in Dual Box only.
1) N-conductor connection required for operation with control cover 6430-7x,
illuminated.
2) N-conductor connection may be required for operation with blind and roller
blind drives with electronic limit switch shut-off. If no N-conductor is available,
capacitor set 6498 can be used.
