Blind control / timers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Busch-Blind control II switch insert ) Busch-Short-time timer insert ) 1
1
Suitable for blind, roller blind and awning drives with countdown timer
mechanical or electronic limit switch shut-off. For time-programmed switching of electrical
With two 230 V multi-way input terminals (Up/Down) for consumers.
group control. With control cover, without cover plate.
With operating mode switch for the following modes: Minimum timer time: 1 second.
normal, louvre, base station, position. Maximum timer time: 9:59:59 hours.
With party function (disables the local control unit) in Rated voltage: 230 V~, +10 % / -10 %
combination with Busch-Blind control II control cover Rated frequency: 50 Hz
6430-xx-xxx, 6066-xx-xxx. Outputs: 1x Normally open contact
Wind alarm, cleaning functions can be accommodated Rated current: 10 A, cos φ 1
via extension input. Rated power: 2300 VA
For control cover 6430-xx-xxx.
For IR control element 6066-xx-xxx. Temperature range (Device): 0 °C to 35 °CIEC 60669-2-1,
For comfort timer control element 6455-101-500. British Standard EN 60669-2-1
Running time: 3 min 6465 U-101-500 2CKA006410A0393 1/10
Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz Mounting 35 mm deep flush 1gang
Outputs: 2x Normally open contact boxes: or Dual Box 3070-2/35 BSDB.
Rated current: 3 A, cos φ 0.5 Cover frames: 1gang frame 1721 BS-2xG
Rated power: 690 VA or Dual Box frame 1722 BSDB-2xG.
2gang product 2gang combination with adapter plate
Control/Signal outputs: 2
Temperature range (Device): 0 °C to 35 °C combinations: APBS in Dual Box only.
neon indicator: not applicable
6411 U-500-101 2CKA006410A0378 1/10
1) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
1) Compatible with types 6411 U/x.
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
11
or 3060 wallbox concrete)
Brightness sensor
For insert 6411U/S-101. Rocker
With 2 m connecting cable. with marking
Measuring range: 15-50,000 lux. As cover for flush-mounted blind control switch/push
switch.
For inserts 2000/4 and 2020/4 US.
Protection class (Device): IP 20
6414-101 2CKA006410A0389 1/10
anthracite 1785 JA-81 2CKA001751A2934 10
Sun sensor ivory white 1785 JA-82 2CKA001751A2748 10
For insert 6411U/S-101. studio white 1785 JA-84-500 2CKA001751A3088 10/100
Measuring range: 5-50,000 lux.
Cover plate
with rotary control, with marking
As cover for flush-mounted blind control switch/push
6482 2CKA006410A0203 1
switch.
For inserts 2712 U, 2713 U and 2722 U, 2723 U.
Protection class (Device): IP 20
anthracite 1740-81 2CKA001710A3623 10
ivory white 1740-82 2CKA001710A3154 10
studio white 1740-84 2CKA001710A3172 10/100

Cover plate )
1
with labelling field
With marking.
For half-cylindrical type switches and blind control
switch/push-switch.
For inserts 2733 USL-101 and 2712 USL-101, 2713 USL-101,
2722 USL-101, 2723 USL-101.
Protection class (Device): IP 20
anthracite 1755 SL/PZ-81-101 2CKA001710A3626 10
ivory white 1755 SL/PZ-82-101 2CKA001710A3157 10
studio white 1755 SL/PZ-84-101 2CKA001710A3175 10
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
