11/114 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
pure stainless steel
Data communication

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Cover plate Cover plate
With hinged lid. with metal mounting plate
For telecommunication inserts with cover plate With screw-type terminal.
50 x 50 mm. Fixed with central locknut.
With cover plate 50 x 50 mm, AMP, Brand-Rex, As cover for pilot devices with a diameter of 22.5 mm
Rutenbeck, BTR, Telegärtner, etc. Without claws.
Surface painted. Surface painted.
Protection class (Device): IP 20 Protection class (Device): IP 20
stainless steel 1746-866 2CKA001710A3769 10 stainless steel 2533-866 2CKA001724A4270 10

Intermediate ring with hinged lid ) ) 2 Cover plate )
1
1
For accommodating cover plates from the Busch-Duro with metal mounting plate
2000® SI program and Reflex SI, e.g. child protection for communication devices.
socket outlets, equipotential, antenna, and ISDN socket With labelling field 60.2 x 10.2 mm.
outlets, etc. Without claws.
Delivery without cover plate. Surface painted.
With sealing ring. Protection class (Device): IP 20
IP 44 only in conjunction with cover frames stainless steel 1758-866 2CKA001724A4272 10
All Weather 44.
Surface painted. 1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
Protection class (Device): IP 44
stainless steel 2518-WD-866 2CKA001719A0221 10
1) Combinable with cover plate 1746-...-101. 1743-04-..., 1743/10-04-... or data inserts
with covers 50 x 50 mm, e.g. from Ackermann, Rutenbeck, BTR, Telegärtner.
2) Combinable only with covers for flush-mounted inserts
11
XLR centre plate
As cover for Neutrik plug connectors, type D series.
Without claws.
Surface painted.
Protection class (Device): IP 20

stainless steel 2553-866 2CKA001724A4403 10

Cover plate
with metal mounting plate
For covering universal data communication connectors
and circular connectors with screwed plug M 16x0.75
(installable in insert) in accordance with DIN 41524,
41529, 45322, 45327, 45328 and 45329.
Knock-out openings 6, 8, 18 mm.
Material stainless steel.
Anti fingerprint.
Protection class (Device): IP 20
stainless steel 1748-866 2CKA001710A3760 10

Cover plate
with metal mounting plate
As cover for BNC and TNC sockets.
Knock-out openings 6, 8, 18 mm.
Material stainless steel.
Anti fingerprint.
Protection class (Device): IP 20
stainless steel 1750-866 2CKA001710A3770 10

Equipotential socket outlet
2gang
Without claws.
For connecting wires up to 1 x 6 mm² and 4 x 2.5 mm².
IEC 60601-1:2005; DIN EN 60601 (VDE 0750-1): July 2007
Connection bolts German Standard DIN 42801.
Surface painted.
Protection class (Device): IP 20
stainless steel 2095 UC-866 2CKA002495A0090 10
