Rocker switches / push switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

Rocker Switch rocker with marking
with small red spherical cap With bell symbol.
As cover for flush-mounted 1gang 1way, 1gang 2way For flush-mounted push switch.
switch, intermediate switch, push-button and control Protection class (Device): IP 20
switch 1gang 2way.
Protection class (Device): IP 20
ivory white 1789-82 2CKA001751A2813 10 ivory white 2520 KI-82 2CKA001751A3177 10/100
studio white 1789-84-500 2CKA001751A3091 10/100 studio white 2520 KI-84-500 2CKA001751A3180 10/100
grey metallic ) 1789-803 2CKA001751A3013 10 grey metallic ) 1 2520 KI-803 2CKA001751A3175 10/100
1
1) Surface painted. 1) Surface painted.

Rocker Switch rocker with marking
with small transparent lens with small transparent lens
As cover for flush-mounted 1gang 1way, 1gang 2way With symbol.
switch, intermediate switch, push-button and control As cover for flush-mounted 1gang 1way, 1gang 2way
switch 1gang 2way. switch, intermediate switch, push-button and control
Protection class (Device): IP 20 switch 1gang 2way.
Protection class (Device): IP 20
ivory white 1789 N-82 2CKA001751A3148 10/100
ivory white 1789 LI-82 2CKA001751A2745 10
studio white 1789 N-84-500 2CKA001751A3151 10/100
studio white 1789 LI-84-500 2CKA001751A3084 10/100
grey metallic ) 1789 N-803 2CKA001751A3146 10/100
1
grey metallic ) 1 1789 LI-803 2CKA001751A3014 10
1) Surface painted.
1) Surface painted.
11
Switch rocker with marking
with small transparent lens Switch rocker with marking
With "Plug" icon. with small transparent lens
As cover for flush-mounted switch 1g1w DP and 3pole With key symbol.
with neon lens and marking "I O" For flush-mounted push switch.
As cover for flush-mounted 1gang 1way, 1gang 2way Protection class (Device): IP 20
switch, intermediate switch, push-button and control
switch 1gang 2way. ivory white 1789 TR-82 2CKA001751A2747 10
Protection class (Device): IP 20
studio white 1789 TR-84 2CKA001751A2755 10
ivory white 1789 ST-82 2CKA001751A3158 10/100
grey metallic ) 1 1789 LI-803 2CKA001751A3014 10
studio white 1789 ST-84-500 2CKA001751A3161 10/100
1) Surface painted.
grey metallic ) 1789 ST-803 2CKA001751A3156 10/100
1
1) Surface painted.
Switch rocker with marking
with small transparent lens
Switch rocker with marking With bell symbol.
With symbol. For flush-mounted push switch.
For flush-mounted switch 1g1w, 1g2w, intermediate, Protection class (Device): IP 20
push switch.
Protection class (Device): IP 20
ivory white 1789 KI-82 2CKA001751A2746 10
studio white 1789 KI-84 2CKA001751A2754 10
ivory white 2520 LI-82 2CKA001751A3187 10/100
grey metallic ) 1 1789 KI-803 2CKA001751A3015 10
studio white 2520 LI-84-500 2CKA001751A3190 10/100
1) Surface painted.
grey metallic ) 2520 LI-803 2CKA001751A3185 10/100
1
1) Surface painted.
1
Rocker ) )
2
with labelling field
Switch rocker with marking With bell symbol.
With key symbol. With pilot lamp for uniform illumination of the labelling
For flush-mounted push switch. field.
Protection class (Device): IP 20 For flush-mounted push switch.
Size of labelling field: 59.7 x 11.7 mm.
Protection class (Device): IP 20
ivory white 2520 TR-82 2CKA001751A3197 10/100 ivory white 1764 NLI/KI-82 2CKA001731A3999 10/100
studio white 2520 TR-84 2CKA001751A3199 10/100 studio white 1764 NLI/KI-84-500 2CKA001731A4002 10/100
grey metallic ) 2520 TR-803 2CKA001751A3195 10/100 grey metallic ) 3 1764 NLI/KI-803 2CKA001731A3997 10/100
1
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
1) Surface painted.
2) Illumination using neon lamp 8353 or incandescent lamp 8344-1 and LED inserts.
3) Surface painted.
