solo®
Rocker switches / push switches

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

2
1
Rocker ) ) Cover plate
with labelling field For card switch.
With pilot lamp for uniform illumination of the labelling For insert 2025 U.
field. Suitable for cards sized 54 x 86 mm.
For flush-mounted switch 1g1w, 1g2w, intermediate, The inner part of the cover plate is made of light-
push switch. conducting plastic, so that the card slot is illuminated.
Size of labelling field: 59.7 x 11.7 mm. Protection class (Device): IP 20
Protection class (Device): IP 20 ivory white 1792-82 2CKA001710A3640 10
ivory white 1764 NLI-82 2CKA001731A1876 10
studio white 1792-84 2CKA001710A3641 10
studio white 1764 NLI-84 2CKA001731A1877 10/100 grey metallic ) 1 1789 H-803 2CKA001751A3019 10
grey metallic ) 1764 NLI/KI-803 2CKA001731A3997 10/100 1) Surface painted.
3
1) For compatible lettering software, visit www.BUSCH-JAEGER-labelingtool.com.
2) Illumination using neon lamp 8353 or incandescent lamp 8344-1 and LED inserts.
3) Surface painted. Switch rocker with marking
For flush-mounted switch 1g1w, 1g2w, intermediate,
push switch.
Switch rocker with marking DO NOT DISTURB
with small red spherical cap Protection class (Device): IP 20
With imprint "0" and "I".
As cover for 2-pole or 3-pole flush-mounted on-off
switch and 2-pole control on-off switch. ivory white 1786/11-82 2CKA001751A2997 10
Protection class (Device): IP 20 studio white 1786/11-84 2CKA001751A2998 10
ivory white 1788-82 2CKA001751A2742 10 grey metallic ) 1 1786/11-803 2CKA001751A3206 10
studio white 1788-84 2CKA001751A2750 10/100 1) Surface painted. 11
grey metallic ) 1788-803 2CKA001751A3017 10
1
1) Surface painted. Switch rocker with marking
For flush-mounted switch 2g 1w, 2g push switch.
DO NOT DISTURB
Switch rocker with marking MAKE UP ROOM
with small red spherical cap Protection class (Device): IP 20
With marking "Heizung".
As cover for flush-mounted 1gang 1way, 1gang 2way
switch, intermediate switch, push-button and control ivory white 1785/11-82 2CKA001751A2991 10
switch 1gang 2way. studio white 1785/11-84 2CKA001751A2992 10
As cover for 2-pole or 3-pole flush-mounted on-off
switch and 2-pole control on-off switch. grey metallic ) 1 1785/11-803 2CKA001751A3204 10
Protection class (Device): IP 20 1) Surface painted.
ivory white 1789 H-82 2CKA001751A2743 10
studio white 1789 H-84 2CKA001751A2751 10 Bell push-switch DND/MUR
with marking "Do not Disturb" and "Make up Room"
grey metallic ) 1789 H-803 2CKA001751A3019 10
1
two seperate LED indicators
1) Surface painted.
with screw-type terminal
Rated voltage: 250 V~
Rated current: 10 ABS EN 60669-1, IEC 60669-1
1
Card switch 10 A )
SP, with normally open contact (operating current) ivory 2029 UC-82 2CKA001751A3168 1
Illuminable.
With N terminal. studio white 2029 UC-84 2CKA001751A3170 1
Rated voltage: 250 V~ grey metallic ) 1 2029 UC-803 2CKA001751A3166 1
Rated current: 10 A 1) Surface painted.
Protection class (Device): IP 20IEC60669-1, British
Standard EN 60669-1
Pull switch ) 1
2025 U 2CKA001012A1713 10
SP, with normally open contact (operating current)
Mounting 35 mm deep flush 1gang With 2-metre pull cord, red handle, and red neon
boxes: or Dual Box 3070-2/35 BSDB. indicator.
2gang product 2gang combination with adapter plate Rated voltage: 250 V~
combinations: APBS in Dual Box only. Rated current: 10 A
delivery form: Adapter plate APBS to be ordered separate. 2020/01 US-101 2CKA001413A1112 10
