11/134 ELECTRICAL INSTALL ATION SOLUTIONS FOR BUILDINGS 2CHC 420 001 C0201

—
solo®
Dimmers

Product Article-No. Order-No. Pack/Qty Product Article-No. Order-No. Pack/Qty

4
5
6
1
2
3
7
4
5
6
1
2
3
Busch-rotary dimmer ) ) ) ) ) ) ) Busch-touch dimmer ) ) ) ) ) )
UP, LED, 2-400 W Flush-mounted, LED, 2-100 W
Very small installation depth: < 20 mm Touch dimmer.
Without claws. 2-wire connection (neutral conductor not required)
With rotary control, two-way switch and soft-catch. Neutral conductor optionally connectable
2-wire connection (neutral conductor not required) (recommended for the connection of low loads
Optimised for dimming of retrofit LED lamps (LEDi). < 10 W/VA). Optimised for dimming of retrofit LED
For dimmable Retrofit-LEDs (LEDi). lamps (LEDi). For incandescent lamps, 230V tungsten
For dimmable Retrofit-LEDs (LEDi) with conventional or halogen lamps and low-voltage halogen lamps with
electronic transformers. conventional transformers or electronic transformers
For incandescent lamps, 230 V tungsten halogen and dimmable halogen energy-saving lamps.
lamps, low-voltage halogen lamps with conventional or Mix operaton of LEDi with conventional loads possible.
electronic transformers and dimmable energy-saving With adjustable minimum brightness.
halogen lamps. The minimum brightness for the leading edge control
Mix operaton of LEDi with conventional loads possible. can be adjusted using the potentiometer.
With manually adjustable operating mode: trailing / The potentiometer at the left limit stop corresponds
leading edge control. with the trailing edge control mode.
With adjustable minimum/maximum brightness. Low-noise level by MOSFET transistors.
Low-noise level by MOSFET transistors. With electronic short-circuit protection.
With electronic short-circuit protection. With electronic overload protection.
With electronic overload protection. With light-level memory and minimum brightness
Without cover plate. memory. Operation also possible via conventional push
Rated voltage: 230 V~, + 10% / - 10% buttons (2020 US, 2021/6 UK). Without control cover.
Rated frequency: 50 Hz/60 Hz For control cover with control lamp 6543-xxx-10x.
Nominal power: 2 - 100 W/VA (leading edge control) For Busch-Remote control IR control cover 6066-xxx-10x.
Nominal power: 2 - 400 W/VA (trailing edge control) For comfort timer control element 6455-101-500.
Protection class (Device): IP 20 For Busch-Watchdog Presence tech 6813-xxx-101 und
11
Temperature range (Device): 0 °C to 35 °CIEC 60669-2-1, 6813/11-xxx.
British Standard EN 60669-2-1 Nominal power: 2 - 100 W/VA (retrofit LED loads).
Nominal power: 10 - 200 W/VA (non-LED loads).
Rated voltage: 230 V~, +10 % / -10 %
6523 UR-103-500 2CKA006512A0345 1/10 Rated frequency: 50 Hz - 60 Hz
Protection class (Device): IP 20
1) Illuminable with neon lamp. Neon lamp included in delivery with cover plate.
Temperature range (Device): 0 °C to 35 °CIEC 60669-2-1,
2) In the case of conventional transformers, take ~20% transformer loss into account.
British Standard EN 60669-2-1
3) In case of electronic transformers, 5 % transformer losses.
4) Also applicable for 1gang 2way installations.

5) Provided with terminal for net disconnection devices.
6) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
6526 U-500 2CKA006512A0323 1/10
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
1) Illuminable with neon lamp. Neon lamp included in delivery with cover plate.
or 3060 wallbox concrete)
2) In the case of conventional transformers, take ~20% transformer loss into account.
7) Recommendation: Please use loads and types of one producer.
3) In case of electronic transformers, 5 % transformer losses.
4) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
5) Recommendation: Please use loads and types of one producer.
6) In connection with 6810-21x-101 and 6800-xx-104 (M) only suitable for switching
retrofit LEDs (for 2-conductor connection).
2
4
3
Busch-rotary dimmer ) ) ) )
1
flush mounted, R, 60-600 W
With rotary control, 2way On-Off switching and
soft-catch.
Leading Edge control.
For incandescent lamps and 230 V tungsten halogen
lamps.
With adjustable minimum brightness.
Without cover plate.
Rated voltage: 230 V~, +10 % / -10 %
Rated frequency: 50 Hz
Rated power: 60 - 600 W
IEC 60669-2-1, British Standard EN 60669-2-1

2250 U-500 2CKA006515A0848 1/10
1) Illuminable with neon lamp. Neon lamp included in delivery with cover plate.
2) Also applicable for 1gang 2way installations.
3) Only in conjunction with standard flush-mounting boxes according to DIN 49073,
Part 1, erect or Busch-Jaeger No. 3040 wallbox stonework, 3050 wallbox cavity wall
or 3060 wallbox concrete)
4) Provided with terminal for net disconnection devices.
